| Item | Parameter |
|---|---|
| Part Number | 6AV7240‑7AC06‑0PA0 |
| Product Series | SIMATIC IPC477D |
| Display | 15‑inch TFT, resistive touch screen |
| Resolution | 1280 × 800 pixels |
| CPU | Intel Core i5‑6442EQ, 4‑Core 1.9 GHz, burst 2.7 GHz, 6MB cache |
| Main Memory | 16 GB DDR4‑SDRAM |
| Storage | 240 GB SATA‑SSD |
| Graphics | Intel HD Graphics 530 |
| Ethernet | 3 × 10/100/1000 Mbps RJ45, PROFINET IRT with switch |
| Fieldbus | Integrated PROFIBUS‑DP interface |
| USB | 4 × USB3.0 rear, 1 × USB3.0 front |
| Serial Interface | 1 × isolated RS232 |
| Expansion Slot | 1 × PCIe x4 |
| Power Supply | 24 V DC industrial power |
| Front Protection | IP65, Rear IP20 |
| Operating Temperature | 0 °C ~ +50 °C |
| Mounting | Panel cut‑out mounting |
| Weight | 4.9 kg |
| Country of Origin | Germany |
