Product Family: SIMOVERT MASTERDRIVES MC (Motion Control) Compact Plus Inverter
Core Electrical Parameters
| Parameter | Value | Notes |
|---|---|---|
| Model | 6SE7012-0TP50 | DC-fed motion control inverter |
| DC Input Voltage | 510–650 V DC | Nominal 600 V DC |
| Output Voltage | 0–380/480 V AC, 3-phase | Adjustable, matching motor voltage |
| Rated Output Current | 2.0 A | Continuous, 3-phase |
| Peak Output Current | 3.2 A | For 10 seconds |
| Continuous Torque Current | 2.4 A | Vector control rated |
| Rated Motor Power | 0.75 kW | At 400 V, 4-pole induction motor |
| Output Frequency Range | 0–400 Hz | Standard; up to 650 Hz with option |
| Control Modes | V/F, Sensorless Vector, Closed-Loop Vector (encoder), Torque Control | High-dynamic motion control |
| Switching Frequency | 2–16 kHz | Default 8 kHz; low-noise option available |
| DC Bus Capacitance | Integrated | For voltage stabilization |
Physical & Environmental Parameters
| Parameter | Value | Notes |
|---|---|---|
| Dimensions (W×H×D) | 45 × 360 × 260 mm | Ultra-slim 45mm width |
| Weight | 3.0 kg | Approx. 6.6 lbs |
| Protection Class | IP20 | Indoor, panel-mounted |
| Cooling | Forced air | 0.002 m³/s airflow |
| Acoustic Noise | ≤ 18 dB(A) | At 50 Hz, low-noise design |
| Operating Temp | 0–40 °C | Derate above 30 °C |
| Storage Temp | -25–+70 °C | |
| Humidity | 5–80% RH | Non-condensing |
| Max Altitude | 1000 m | Derate above 1000 m |
| Vibration | IEC 60068-2-6 | 1g, 10–200 Hz |
| Shock | IEC 60068-2-27 | 15g, 11ms |
Performance & Control Features
| Feature | Specification | |
|---|---|---|
| Speed Regulation Accuracy | ±0.01% (closed-loop with encoder) | ±0.5% (sensorless vector) |
| Torque Response | < 10 ms | High dynamic for motion control |
| Overload Capacity | 150% for 60s, 200% for 3s | Standard overload |
| Positioning Accuracy | ±1 pulse (with high-res encoder) | For indexing/positioning tasks |
| Control Interfaces | Analog: 2×AI, 2×AO; Digital: 6×DI, 3×DO | Isolated, configurable |
| Encoder Support | TTL, HTL, Sin/Cos, Resolver | Closed-loop feedback |
| Communication | PROFIBUS DP (standard), PROFINET (option), DeviceNet | Industrial network connectivity |
| Protection Functions | Overcurrent, overvoltage, undervoltage, overtemperature, earth fault, motor overload, short circuit | Comprehensive protection |
Electrical Connections
| Connection | Specification | |
|---|---|---|
| DC Input Terminals | 3×10 mm² (E-CU) | For DC bus connection |
| Motor Output Terminals | 3×4 mm² | U, V, W to motor |
| Control Terminals | Screw terminals | 0.5–2.5 mm² |
| Auxiliary Power | 24 V DC ±10% | For control logic |
General Specifications
| Item | Details | |
|---|---|---|
| Product Status | Discontinued; successor: 6SE7012-0TP70 | |
| Certifications | CE, UL, cUL, C-Tick | Industrial safety standards |
| Control Unit | CUVC (Compact Universal Control) | Standard on MC series |
| Software Version | V2.xx | Latest firmware for motion control |
| Mounting | Vertical panel mount | DIN rail or direct screw fix |
