| Full Article Number |
6SL3325-1TE41-2AA3 |
| Product Series |
SINAMICS S120 Cabinet Liquid-Cooled Motor Module (Inverter Unit) |
| Product Type |
Chassis-2 liquid-cooled single motor inverter |
| Country of Origin |
Germany |
| DC Link Input Voltage |
510 VDC ~ 720 VDC (matched to 3AC 380–480V mains) |
| Rated DC Link Current |
1380 A |
| AC Output Voltage Range |
380 V ~ 480 V 3-phase AC |
| Rated Output Power |
710 kW (400V standard grid condition) |
| Rated Output Current |
1260 A |
| Output Frequency Range |
0 ~ 500 Hz, compatible with 50/60Hz mains |
| Pulse Frequency |
Rated 1.25 kHz; adjustable up to 7.5 kHz (derating applies) |
| Cooling Medium |
Deionized water / ethylene glycol mixed coolant |
| Standard Inlet Coolant Temperature |
25 °C (allowable range: 5 ~ 40 °C) |
| Minimum Coolant Flow Rate |
30 L/min |
| Max Permissible Inlet Pressure |
6 bar |
| Max Allowable Pressure Drop |
1.1 bar |
| Auxiliary Control Supply |
DC 24 V, rated 1.5 A |
| Communication Interface |
DRIVE-CLiQ (connect CU320-2 / SIMOTION D control units) |
| Protection Class |
IP00 (built-in cabinet installation) |
| Overall Dimensions (W×H×D) |
295 mm × 1491 mm × 545 mm |
| Net Weight |
220 kg (220,000 kg in screenshot is webpage display bug) |
| Operating Ambient Temp |
0 °C ~ +40 °C full 710kW rated power; derating 40–50 °C |
| Storage / Transport Temp |
-25 °C ~ +70 °C |
| Relative Humidity |
5% ~ 95% RH, no condensation, no icing |
| Vibration Resistance |
IEC 60068-2-6: 10–100 Hz, 0.1 g |
| Shock Resistance |
IEC 60068-2-27: 10 g, 6 ms pulse |
| Built-in Hardware Protection |
Overcurrent, overvoltage, undervoltage, overheat, earth fault, short circuit |
| Compatible Line Modules |
6SL3334 series liquid-cooled BLM/SLM/ALM 380–480V rectifier units |
| Certifications |
CE, UL, cULus, EAC, GL marine certification, RoHS 2.0 compliant |
