| Basic Model Info |
Article Number |
6SL3325-1TG41-3AA0 |
|
Product Series |
SINAMICS S120 Cabinet Modules, Liquid-cooled Drive System |
|
Product Type |
Liquid-cooled Motor Module (Inverter Unit) |
|
Country of Origin |
Germany |
|
Protection Class |
IP20 (For cabinet internal mounting) |
|
Compatible Control Unit |
CU320-2 / SIMOTION D via DRIVE-CLiQ |
| DC Link Input Data |
DC Link Voltage Range |
675 VDC ~ 1035 VDC |
|
Rated DC Link Current |
1395 A |
|
Built-in DC Capacitance |
19330 µF |
| Motor Output Electrical Data |
Rated Output Power |
1200 kW (400V mains standard condition) |
|
Adjustable Output Voltage |
0 ~ 690 V 3-phase AC |
|
Rated Output Current |
1270 A |
|
Output Frequency Range |
0 ~ 500 Hz, compatible with 50/60Hz mains |
|
Output Phase |
3 phases AC |
| Auxiliary Power Supply |
Control Auxiliary Supply |
DC 24 V, rated 1.5 A |
| Liquid Cooling System Specs |
Cooling Medium |
Deionized water / Ethylene glycol mixture |
|
Standard Inlet Water Temp |
25 ℃ (Allowable range: 5 ~ 40 ℃) |
|
Minimum Coolant Flow Rate |
32 L/min |
|
Max Allowable Inlet Pressure |
6 bar |
|
Max Permissible Pressure Drop |
1.2 bar |
| Mechanical Dimension & Weight |
Overall Dimension (W×H×D) |
295 mm × 1516 mm × 545 mm |
|
Net Weight |
220 kg (220,000 kg shown in screenshot is webpage display error) |
|
Mounting Type |
Vertical cabinet built-in installation |
| Environmental Conditions |
Operating Ambient Temp |
0 ℃ ~ +40 ℃ (Full 1200kW rated power); derating above 40℃ up to 50℃ |
|
Storage / Transport Temp |
-25 ℃ ~ +70 ℃ |
|
Relative Humidity |
5% ~ 95 %, no condensation, no icing |
|
Vibration Resistance |
IEC 60068-2-6: 10~100Hz, 0.1g |
|
Shock Resistance |
IEC 60068-2-27: 10g, 6ms |
| Certifications & Standards |
Certifications |
CE, UL, cULus, EAC, GL Marine Approval |
|
Industrial Compliance Standards |
IEC 61800-1/-2/-3, EN 60204-1, EN 61000-6-2 |
|
Environmental Standard |
RoHS 2.0 Restriction of Hazardous Substances |
| Functional Features |
Communication Interface |
DRIVE-CLiQ (For motor encoder & controller connection) |
|
Integrated Protection |
Hardware protection: Overcurrent, Overvoltage, Undervoltage, Overheat, Earth fault, Short circuit |
|
Matching Line Modules |
Compatible with 6SL3334 series liquid-cooled ALM/BLM/SLM active/basic line modules |
