- Part Number: 6AV6545-0DB10-0AX0
- Product Name: SIMATIC HMI MP 370 15″ Multi Panel, Touch Operation
- Status: Discontinued (Spare parts only; new orders not accepted)
- Key Features: 15.1″ color TFT touch display, Windows CE 3.0, MIPS processor, 24V DC industrial supply, front IP65, multiple serial/Ethernet interfaces, configurable via ProTool V6 SP2+ / WinCC flexible 2004+
1. Display & User Interface
| Parameter | Value |
|---|---|
| Display Type | Color TFT (256 colors) |
| Diagonal | 15.1″ (308 × 232 mm) |
| Resolution | 1024 × 768 pixels |
| Touch Type | Analog resistive touch |
| Backlight MTBF (25°C) | ~50,000 h |
| Front IP Rating | IP65 |
| Rear IP Rating | IP20 |
| Mounting Orientation | Vertical only |
| Max Tilt (no external vent) | ±35° |
| Control Options | Touch only (no physical membrane keys) |
| Input Support | Numeric/alphanumeric/hex keyboard; USB mouse/keyboard/barcode reader |
| Acoustics | Buzzer |
2. Electrical Parameters
| Parameter | Value |
|---|---|
| Supply Voltage | 24 V DC (industrial) |
| Voltage Range | 20.4 … 28.8 V DC |
| Rated Input Current | 1.8 A |
| Typical Power Consumption | 41 W |
| Inrush Current (I²t) | ≤ 0.5 A²·s |
| UPS Connectable | Yes (serial) |
| Backup Battery | Optional 3.6 V; min backup duration 3 h |
| Cooling | Passive convection (fanless) |
3. Hardware & Memory
| Parameter | Value |
|---|---|
| Processor | MIPS |
| OS | Windows CE 3.0 |
| User Data Memory | 7168 KB (usable) / 5689 KB (available) |
| Recipe Memory | 128 KB integrated Flash (expandable) |
| Real-Time Clock | Battery-backed hardware RTC (synchronizable) |
| Expansion Slots | 1× PC Card slot, 1× CF Card slot |
| USB | 1× USB (for mouse/keyboard/barcode) |
4. Interfaces & Communication
| Interface | Specification |
|---|---|
| Ethernet | 1× RJ45 (max 12 Mbit/s; TCP/IP, Modbus TCP, S7 communication) |
| Serial | 1× TTY, 2× RS232, 1× RS422, 1× RS485 (max 12 Mbit/s) |
| Fieldbus Support | PROFIBUS DP (via RS485), Modbus, SNP (GE-Fanuc), OMRON LINK/Multilink |
| PLC Compatibility | S7-300/400/200, LOGO!, Modicon, Allen‑Bradley, Mitsubishi, GE-Fanuc |
| Configuration Transfer | Ethernet / PC Card / CF Card |
5. Mechanical Data
| Parameter | Value |
|---|---|
| Weight (approx.) | ~7.6 kg (without packaging) |
| Housing (Front) | Sealed plastic (IP65) |
| Mounting | Panel/cabinet mount (clamps included) |
6. Ambient & Environmental
| Parameter | Value |
|---|---|
| Operating Temperature (vertical) | 0 °C … +50 °C |
| Operating Temperature (max tilt) | 0 °C … +35 °C |
| Storage/Transport Temperature | -20 °C … +60 °C |
| Relative Humidity (Operation) | ≤ 85% (non-condensing) |
| Certifications | CE, cULus, FM Class I Div. 2, EX Zone 2/22, C-TICK |
| Vibration/Shock | IEC 60068-2-6 (vibration), IEC 60068-2-27 (shock) |
7. Software & Functional Specs
| Feature | Value |
|---|---|
| Configuration Software | ProTool V6 SP2+, WinCC flexible 2004+ (Standard) |
| Variables | 2048 total; 400 per screen |
| Screens | 300 process images |
| Alarms | 32 alarm classes; 4000 analog messages; bit messages supported |
| Recipes | 500 recipes; 1000 data records/recipe; 1000 entries/record |
| Scripting | Visual Basic Script (50 scripts, 100 lines/script under ProTool; 100 under WinCC flexible) |
| Languages | 32 project languages; 5 online/runtime languages |
| Remote Access | Sm@rtService, Sm@rtAccess (WinCC flexible) |
| Additional Apps | ProAgent, Internet Explorer, ThinClient, Soft-PLC |
