| Item | Specification |
|---|---|
| Order Number | 6ES7647‑8BB31‑7CA1 |
| Product Family | SIMATIC IPC227E Nanobox PC |
| Processor | Intel Celeron N2930, Quad‑Core, 1.83 GHz |
| Main Memory (RAM) | 8 GB DDR3L SO‑DIMM |
| Mass Storage | 240 GB 2.5‑inch SATA SSD |
| Power Supply | 24 V DC industrial power input |
| Video Interface | 1 × DisplayPort |
| Ethernet Interface | 2 × RJ45 10/100/1000 Mbps Gigabit Ethernet |
| USB Interfaces | 1 × USB3.0, 3 × USB2.0 |
| Serial Interface | Without RS232 / RS422 / RS485 COM ports |
| Expansion Slot | 1 × CFast memory card slot |
| Monitoring Function | Watchdog timer, Temperature monitoring, Status LED indicators |
| Operating System | Windows 10 IoT Enterprise LTSB 2016 64‑bit, MUI (EN/DE/FR/IT/ES) pre‑installed |
| SIMATIC Runtime Software | Without SIMATIC software |
| Mounting | DIN‑rail mounting, wall‑mount optional |
| Protection Class | IP40 (housing) |
| Operating Temperature | 0 °C … +55 °C |
| Storage / Transport Temperature | -20 °C … +60 °C |
| Relative Humidity | 5 % … 95 % RH, non‑condensing |
| Dimension (W × H × D) | 191 mm × 100 mm × 64 mm |
| Approx. Weight | 1.2 kg |
| Certifications | CE, cULus, FCC Class A, RCM, EAC |
