Basic Information
- Model: ATV630D45N4
- Series: Altivar Process 630
- Type: Variable Speed Drive (VFD)
- Mounting: Wall-mount
- Protection: IP21 (front), UL Type 1
- Cooling: Forced air cooling
Power & Voltage Ratings
表格
| Parameter | Value |
|---|---|
| Supply Voltage | 380–480 VAC, 3‑phase, 50/60 Hz |
| Voltage Tolerance | -15% to +10% |
| Normal Duty (ND) | 45 kW / 60 HP |
| Heavy Duty (HD) | 37 kW / 50 HP |
| Output Frequency | 0.1–500 Hz |
| Switching Frequency | 2–12 kHz (default: 4 kHz) |
Current Ratings (3‑phase)
表格
| Condition | Line Current (A) | Output Current (A) |
|---|---|---|
| Normal Duty (ND) @ 380 V | 79.8 A | 88 A |
| Normal Duty (ND) @ 480 V | 69.1 A | 88 A |
| Heavy Duty (HD) @ 380 V | 67.1 A | 74.5 A |
| Heavy Duty (HD) @ 480 V | 59.0 A | 74.5 A |
| Prospective Short‑Circuit Current | 50 kA |
Performance & Overload
表格
| Parameter | Value |
|---|---|
| Overload (ND) | 120% for 60 s |
| Overload (HD) | 150% for 60 s |
| Starting Torque | Up to 200% at 0 Hz (vector control) |
| Speed Regulation | ±0.01% (closed‑loop vector) |
| Torque Response | < 5 ms |
Environmental & Physical
表格
| Parameter | Value |
|---|---|
| Ambient Temperature | -15 °C to +50 °C (no derating) |
| Altitude | ≤ 1000 m (no derating) |
| Dimensions (W×H×D) | 226 × 673 × 271 mm |
| Weight | 28.7 kg |
| EMC Filter | Integrated C2/C3 (EN/IEC 61800‑3) |
I/O & Communication
表格
| Category | Details |
|---|---|
| Analog Inputs | 3 × AI (0–10 V / 0–20 mA, 12‑bit) |
| Analog Outputs | 2 × AQ (0–10 V / 0–20 mA) |
| Digital Inputs | 8 × DI (sink/source) |
| Relay Outputs | 3 × configurable relays (3 A @ 250 VAC) |
| Communication | Modbus RTU, Modbus TCP, Ethernet; optional: Profibus, PROFINET |
Safety & Certifications
表格
| Item | Details |
|---|---|
| STO (Safe Torque Off) | SIL3 / PLe, Cat. 3 / PL e |
| Certifications | CE, UL 508C, CSA, ATEX Zone 2/22 |
