ATV630D45N4 is a Schneider Electric Altivar Process drive: 45 kW (Normal Duty) / 37 kW (Heavy Duty), 3‑phase 380–480 V AC.
Core Electrical Parameters
| Parameter | Normal Duty (ND) | Heavy Duty (HD) | Notes |
|---|---|---|---|
| Rated Motor Power | 45 kW / 60 HP | 37 kW / 50 HP | |
| Supply Voltage | 380–480 V AC, 3‑phase | 380–480 V AC, 3‑phase | ±10% tolerance |
| Supply Frequency | 50/60 Hz | 50/60 Hz | ±5% tolerance |
| Continuous Output Current | 88 A @ 4 kHz | 74.5 A @ 4 kHz | |
| Max Transient Current | 105.6 A (60 s) | 111.8 A (60 s) | 120% ND / 150% HD |
| Line Current (Input) | 79.8 A (380 V)
69.1 A (480 V) |
67.1 A (380 V)
59 A (480 V) |
|
| Apparent Power | 57.4 kVA (480 V) | 49.1 kVA (480 V) | |
| Overload Capacity | 120% for 60 s | 150% for 60 s | |
| Output Frequency | 0.1–500 Hz | 0.1–500 Hz | |
| Nominal Switching Freq | 4 kHz | 4 kHz | Adjustable 2–12 kHz |
| Power Factor | ≥0.9 (full load) | ≥0.9 (full load) | |
| Torque Accuracy | ±0.5% (full load) | ±0.5% (full load) | Vector control |
Mechanical & Environmental
| Parameter | Value |
|---|---|
| IP Rating | IP21 (UL Type 1) |
| Cooling | Forced convection |
| Dimensions (H×W×D) | 673 mm × 226 mm × 271 mm |
| Weight | 28.7 kg |
| Operating Temp | -10°C to +50°C (derate above 40°C) |
| Storage Temp | -25°C to +70°C |
| Humidity | 5–95% RH (non‑condensing) |
| EMC Filter | Integrated, Category C2/C3 (EN 61800‑3) |
Control & Safety
| Feature | Specification |
|---|---|
| Control Modes | V/F, Sensorless Vector, Flux Vector |
| Motor Compatibility | Asynchronous, Permanent Magnet Synchronous |
| Safety | STO (Safe Torque Off), SIL 3 |
| Analog I/O | 3 AI, 2 AO (configurable) |
| Digital I/O | 6 DI, 3 Relay Outputs (NO/NC) |
| Communication | Modbus, CANopen, Ethernet‑IP, Profinet (optional) |
