| Basic Information |
Model |
ATV630U07N4 |
Altivar Process 630 Series |
|
Product Type |
Variable Speed Drive (VFD) |
Forced convection, wall‑mount |
|
IP Rating |
IP21 / NEMA Type 1 |
Indoor protection |
|
Weight |
4.5 kg |
|
|
Dimensions (W×H×D) |
144 × 203 × 350 mm |
|
| Input Ratings |
Supply Voltage |
380–480 VAC, 3‑phase |
50/60 Hz auto‑adaptive |
|
Phases |
3‑phase |
|
| Output Ratings |
Normal Duty Motor Power |
0.75 kW (1 HP) |
Continuous variable torque |
|
Heavy Duty Motor Power |
0.37 kW (0.5 HP) |
Constant torque |
|
Continuous Output Current (4 kHz) |
2.2 A |
Normal duty |
|
Heavy‑Duty Output Current (4 kHz) |
1.5 A |
Heavy duty |
|
Output Voltage |
3‑phase, matched to input |
|
|
Output Frequency Range |
0.1–500 Hz |
|
|
Nominal Switching Frequency |
4 kHz |
|
|
Switching Frequency Range |
1–16 kHz |
Derating required above 4 kHz |
| Motor Compatibility |
Motor Types |
Asynchronous, Synchronous, Special Motors |
|
|
Motor Voltage |
Up to 480 VAC |
|
|
Control Modes |
V/F, Sensorless Vector, Flux Vector |
|
| Performance |
Overload Capacity |
110% for 60 s (normal duty); 150% for 60 s (heavy duty) |
|
|
Control Accuracy |
±0.01 Hz (closed loop) |
|
|
Torque Response |
< 10 ms (sensorless vector) |
|
| Environmental |
Operating Temperature |
-15 °C to +50 °C |
Derate above 40 °C |
|
Storage Temperature |
-40 °C to +70 °C |
|
|
Altitude |
Up to 1000 m |
Derate above 1000 m |
|
Humidity |
5–95% RH, non‑condensing |
|
| Communication |
Standard |
Modbus RTU (RS‑485) |
Built‑in |
|
Optional |
Ethernet, Modbus TCP, Profibus DP, PROFINET |
Via communication card |
| I/O Interfaces |
Analog Inputs (AI) |
3 × configurable (0–10 V / 0–20 mA, 12‑bit) |
|
|
Analog Outputs (AQ) |
2 × configurable (0–10 V / 0–20 mA, 10‑bit) |
|
|
Digital Inputs (DI) |
8 × configurable (24 VDC) |
|
|
Relay Outputs |
3 × (R1: fault NO/NC; R2/R3: configurable NO) |
|
| Certifications |
Safety |
ATEX (Zone 2/22), DNV‑GL, TÜV, UL, CSA, CE, EAC |
|
|
Compliance |
IEC 61000‑3‑12, IEC 61508, IEC 61800‑3, EN ISO 13849‑1, UL 508C |
|
| Power Dissipation |
Forced Convection |
44 W at 380 V |
Switching frequency 4 kHz |
|
Natural Convection |
172 W at 380 V |
Switching frequency 4 kHz |
