| General Information |
Model |
ATV630U22N4 |
|
Series |
Altivar Process ATV630 |
|
Supply Phases |
3‑phase AC |
|
Mounting |
Wall‑mount, vertical orientation |
| Power & Rating |
Motor Power (Normal Duty) |
2.2 kW / 3 HP |
|
Motor Power (Heavy Duty) |
1.5 kW / 2 HP |
|
Rated Supply Voltage |
380…480 VAC (−15…+10% tolerance) |
|
Supply Frequency |
50…60 Hz (−5…+5% tolerance) |
|
Line Current (Normal Duty) |
4.3 A @ 380 VAC; 3.8 A @ 480 VAC |
|
Line Current (Heavy Duty) |
3.1 A @ 380 VAC; 2.9 A @ 480 VAC |
|
Continuous Output Current |
5.6 A (4 kHz switching frequency, normal duty) |
|
Continuous Output Current |
4.0 A (4 kHz switching frequency, heavy duty) |
|
Max. Transient Current |
6.2 A (60 s, normal duty); 6.0 A (60 s, heavy duty) |
|
Apparent Power (Normal Duty, 480 VAC) |
3.2 kVA |
|
Apparent Power (Heavy Duty, 480 VAC) |
2.4 kVA |
|
Prospective Short‑Circuit Current (Isc) |
50 kA |
| Output Performance |
Output Frequency Range |
0.0001…500 Hz |
|
Nominal Switching Frequency |
4 kHz |
|
Adjustable Switching Frequency |
2…12 kHz |
|
Control Modes |
V/F, Sensorless Vector, Flux Vector |
|
Max. Output Voltage |
≤ supply voltage (380…480 VAC) |
|
Motor Compatibility |
Asynchronous, permanent magnet, synchronous reluctance |
| Protection & Safety |
Degree of Protection |
IP21 (IEC 60529); UL Type 1 (UL 508C) |
|
Safety Functions |
STO (Safe Torque Off) to SIL 3; optional SLS, SS2, SLP |
|
Short‑Circuit Protection |
Integrated |
|
Motor Overload Protection |
Thermal motor model (IEC 61800‑5‑1) |
|
Overvoltage / Undervoltage |
Line‑side monitoring |
|
EMC Immunity |
Level 3 (IEC 61000‑4‑2,‑4‑3,‑4‑5,‑4‑8,‑4‑11) |
|
EMC Emission |
C2 (IEC 61800‑3); C3 (environment 2) |
| Environment & Physical |
Operating Temperature |
−15…50 °C (no derating); −15…60 °C (derated) |
|
Storage / Transport Temperature |
−40…70 °C |
|
Operating Altitude |
≤ 1000 m (no derating); > 1000 m (derating required) |
|
Vibration Resistance |
1 gn (13…200 Hz); 1.5 mm p‑p (2…13 Hz) (IEC 60068‑2‑6) |
|
Cooling |
Forced convection (38 m³/h airflow) |
|
Dimensions (W × H × D) |
144 mm × 350 mm × 203 mm |
|
Weight |
Approx. 6 kg (13.2 lbs) |
| Communication & I/O |
Standard Communication |
Modbus RTU (RS‑485), Ethernet, Modbus TCP |
|
Discrete Inputs |
8 configurable |
|
Analog Inputs |
3 (0…10 VDC / 0…20 mA / 4…20 mA; PTC, Pt100/1000, KTY84) |
|
Analog Outputs |
2 (0…10 VDC / 0…20 mA) |
|
Relay Outputs |
3 |
|
Preset Speeds |
16 user‑definable |
| Certifications & Standards |
Approvals |
CE, CSA, UL, cUL, EAC, ATEX (Zone 2/22), DNV‑GL |
|
Standards |
IEC 61000‑3‑12, IEC 61508, IEC 60721‑3, EN ISO 13849‑1, IEC 61800‑5/-12/-51 |
