6AG4104-4GF12-3XX0
| Order Number | 6AG4104-4GF12-3XX0 |
| Product Name | SIMATIC IPC547G (Rack PC, 19″, 4HU) |
| Front Interfaces | 2x USB 3.0 |
| Rear Interfaces | 2x Intel Gigabit Ethernet, 2x PS/2, Audio |
| Slots | 7 slots total: 5x PCI Express, 2x PCI |
| Monitoring Features | Temperature and Fan monitoring; Watchdog |
| Card Retainer | Included |
| Processor | Core i5-6500 (4 cores / 4 threads, 3.2 GHz base / 3.6 GHz turbo, 6 MB cache, iAMT) |
| Motherboard / Chipset | Chipset C236; 1x DVI-D, 2x DisplayPort V1.2, 4x USB 3.0 (rear), 4x USB 2.0 (rear), 1x USB 2.0 (internal), 1x COM 1; RAID onboard |
| RAID Configuration | RAID1 |
| Storage | 1 TB total (2x 1 TB HDD) internal; shock tolerance: 1 g; vibration tolerance: 0.2 g |
| Memory (RAM) | 8 GB DDR4 SDRAM (2x 4 GB), Dual Channel |
| Chassis Finish | Enclosure blue chromated |
| Power Supply | 100/240V AC industrial power supply unit |
| Optical Drive | DVD±RW (slim) |
| Additional Ports | Serial (COM2) + Parallel (LPT) |
| Graphics | Graphics onboard (integrated) |
| Operating System | Without operating system |
| Expansions | Without expansions (software) |
| Line Cable | Without line cable |
| warranty | 1 YEAR |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
