6SL3210-1PH31-0UL0
SINAMICS G120 Power Module PM240-2 Unfiltered SINAMICS G120 Power Module PM 240-2 Unfiltered with integrated braking chopper 500-690 V 3 AC +10/-20% 47-63 Hz Power high overload: 75 kW at 200% 3 s, 150% 57 s, 100% 240 s; Ambient temperature -20 to +50 °C (HO); Power Low overload: 90 kW at 150% 3 s, 110% 57 s, 100% 240 s; Ambient temperature -20 to +40 °C (LO) 708x 305x 357 (HxWxD), FSF Degree of protection IP20 without control Unit and operating unit Released as of CU firmware version V4.7 HF8
| Order Number | 6SL3210-1PH31-0UL0 |
| Product Family | SINAMICS G120 |
| Product Type | Power Module PM240‑2 (Unfiltered) |
| Built‑in Component | Integrated braking chopper |
| Input Voltage | 3 AC 500 – 690 V +10% / -20% |
| Input Frequency | 47 – 63 Hz |
| Output Power – High Overload (HO) | 75 kW • 200% for 3 s • 150% for 57 s • 100% for 240 s Ambient temp: –20 °C to +50 °C |
| Output Power – Low Overload (LO) | 90 kW • 150% for 3 s • 110% for 57 s • 100% for 240 s Ambient temp: –20 °C to +40 °C |
| Dimensions (H × W × D) | 708 × 305 × 357 mm |
| Frame Size | FSF |
| Degree of Protection | IP20 |
| Included Components | Without control unit and without operating unit (must be ordered separately) |
| Firmware Compatibility | Released as of CU firmware version V4.7 HF8 |
| Net Weight | 61.000 kg |
| Packaging Dimensions (W × H × D) | 469.00 × 745.00 × 385.00 mm |
| Country of Origin | Germany |
