| Item | Parameter Value |
|---|---|
| MLFB Order No. | 6AV7882-0CA10-2NA0 |
| Product Line | SIMATIC IPC277E Nanopanel Industrial Panel PC |
| Display | 12″ TFT LCD, 1280 × 800 WXGA, analog resistive single touch |
| Front Protection | IP65 / NEMA 4X |
| Rear Housing Protection | IP20 |
| Backlight MTBF (25°C) | 80,000 hours |
| Cooling Type | Fanless passive cooling |
| CPU | Intel Celeron N2807, 2 cores / 2 threads |
| CPU Frequency | Base 1.58 GHz, Burst 2.16 GHz, L2 Cache 1 MB |
| Onboard Graphics | Intel HD Graphics |
| System Memory | 2 GB DDR3L, max expandable to 8 GB |
| Internal Storage | 80 GB industrial replaceable SATA SSD |
| Expansion Interface | CFast card slot for data backup & logging |
| Ethernet | 2 × Gigabit RJ45 (10/100/1000 Mbps, PROFINET supported) |
| USB Ports | 1 × USB3.0 (rear); 3 × USB2.0 (2 rear + 1 front service port) |
| Serial Port | 1 × COM1, configurable RS232 / RS422 / RS485 |
| External Display Output | 1 × DisplayPort |
| Operating System | Windows Embedded Standard 7E SP1 64-bit, English single language |
| Pre-installed Runtime | WinCC RT Advanced V15, 4096 points, recipe and archive license |
| Power Supply | 24 V DC, input range 19.2 V ~ 28.8 V DC |
| Max Power Consumption | 38 W (full load) |
| Front Panel Size (W × H) | 334 mm × 244 mm |
| Overall Depth | 73 mm |
| Mount Cutout (W × H) | 314 mm × 224 mm |
| Net Weight | Approx. 2.75 kg |
| Operating Temp (Vertical) | 0 °C ~ +50 °C |
| Storage & Transport Temp | -20 °C ~ +60 °C |
| Relative Humidity | 5% – 90% RH, non-condensing |
| Vibration Standard | IEC 60068-2-6 compliant |
| Shock Standard | IEC 60068-2-27 compliant |
| Certifications | CE, cULus, UKCA, RoHS |
| ECCN Code | 5A992 |
| Origin | Germany |
| Lifecycle Status | Discontinued, PM410 phase-out status |
