6AV7241-1BA37-0FA0
SIMATIC IPC 477E 15″ touch (1280 x 800); with front USB; 4 USB (back), Ethernet (10/100/1000); Celeron G3902E; 3x Gbit Ethernet (IE/PN); 4 GB 2x RS 232/RS 485; without PCIe; Windows 10 IoT Enterprise 2016 LTSB (64-bit) for Celeron, i3 and i5; Without replaceable mass storage; 240 GB solid-state drive SATA Without SIMATIC software; 24 V DC industrial power supply
| Order Number | 6AV7241-1BA37-0FA0 |
| Product Name | SIMATIC IPC 477E |
| Display | 15″ Touchscreen (1280 × 800 resolution) |
| Front Interface | 1 × USB (front accessible) |
| Rear Interfaces | 4 × USB; 1 × Ethernet (10/100/1000) |
| Processor | Intel Celeron G3902E |
| Network | 3 × Gigabit Ethernet (IE/PN compatible) |
| Memory (RAM) | 4 GB |
| Serial Ports | 2 × RS‑232 / RS‑485 (configurable) |
| Expansion Slots | None (without PCIe) |
| Pre‑installed OS | Windows 10 IoT Enterprise 2016 LTSB (64‑bit), licensed for Celeron, i3, and i5 processors |
| Mass Storage | Not replaceable (fixed) |
| Storage Drive | 240 GB SATA solid‑state drive (SSD) |
| Software Package | Supplied without SIMATIC software |
| Power Supply | 24 V DC industrial power supply unit |
| warranty | 1 YEAR |
| Net Weight (kg) | 7,100 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
