Technical specifications for 22C-D170A103
| Input Voltage | 342-528VAC |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer: | Rockwell Automation / Allen-Bradley |
| Input Phase: | 3-Phase |
| Input Current: | 170 A |
| Output Voltage: | 0-460VAC |
| Applicable Motor Rating: | 90kW (125.0 HP) |
| Control Method: | V/Hz, Slip compensation, Process PID |
| Embedded I/O: | Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) Open Output; Two (2) Form C Contacts Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: Two (2) Analog Input 0-10VDC; 0- 20mA |
| Installation: | Panel Mount |
| Enclosure Rating: | IP20 / NEMA UL Open Type |
| Built-in communication port: | RS485 |
| Optional communication protocols: | BacNet; LonWorks; ProfiBus; Ethernet; DeviceNet; ControlNet |
| Part Number/Catalog No. | 22C-D170A103 |
| Product Line | Powerflex 400 |
| Drive Type | Fan & Pump |
| Horsepower | 125 |
| Phase | Three-Phase |
| Enclosure | Panel Mount – IP30, NEMA/UL Type 8 |
| Amperage | 170 Amps |
| UPC | 820919456589 |
