Technical specifications for 22F-D6P0N113
| Manufacturer | Rockwell Automation |
|---|---|
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 22F-D6P0N113 |
| Manufacturer | Allen Bradley / Rockwell Automation |
| Product Line | Powerflex 4M |
| Drive Category | PowerFlex 4M Adjustable Frequency AC Drive |
| Amperage | 6 |
| Part number | 22F-D6P0N113 |
| Wattage | 2.2 Kilowatt |
| Input Voltage: | 380-480 VAC |
| Enclosure Type | Open- IP20 |
| Input phase: | 3-Phase |
| Input Power | 480 Volts- Alternating Current |
| Output Voltage: | 0-460VAC |
| Phase | Three-Phase |
| Output Phase: | 3-Phase |
| Filter | With Internal CE Compliant Filter |
| Output Power | 3.0 HP or 2.2 kW |
| Horsepower | 3 Horsepower |
| Output current | 6.0 A |
| Discrete Input: | Five (5) 24 VDC discrete inputs |
| Analog input: | Two (2) analog input |
| Discrete output | Two (2) Form C relay output |
| Braking | Non installed |
| EMC Filter | Installed |
| Enclosure | IP20 NEMA/Open |
| Frame | B |
| Interface Module | Standard keypad |
| Communication ports: | RS485 |
| Control Method: | V/Hz Control |
