Technical specifications for 25B-A4P8N114
| Brand | Allen-Bradley |
|---|---|
| Part Number/Catalog No. | 25B-A4P8N114 |
| Output Current | 17.0 A |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Family: | PowerFlex 40P |
| Input Voltage: | 240VAC |
| Input Phase: | 1-Phase |
| Output Voltage: | 0-230VAC |
| Output Phase: | 3-Phase |
| Output Power: | 0.75 kW (1.0 HP) |
| I/O: | Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) N.O.; One (1) N.C. Contacts; Two (2) Digital / Optocoupler Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: One (1) Analog Input 0-10VDC; 0- 20mA |
| Installation: | Panel Mount / DIN Rail |
| Zero Stacking: | Supported |
| Enclosure Rating: | IP20 / NEMA UL Type Open |
| Control Method: | Ethernet I/P / RS485 |
| Optional communication protocols: | Dual Ethernet I/P; DeviceNet; ProfiBus DP |
| Series | PowerFlex 525 Drive |
| Voltage | One Phase, 240VAC |
| Enclosure Type | IP20 NEMA / Open Type |
| Interface Module | Standard |
| Frame Size | Frame A |
| EMC Filtering Options | Filter |
