| Basic Identification |
MLFB Order Number |
6AV7843-0BD10-0WB0 |
|
Full Product Model |
SIMATIC IPC477G Nanopanel Industrial Panel PC |
|
Manufacturer |
SIEMENS AG |
|
Lifecycle Status |
PM300, Active production series |
| Display Module |
Screen Size |
15-inch TFT Wide LCD |
|
Native Resolution |
1280 × 1024 SXGA |
|
Touch Type |
Capacitive multi-touch screen (10-point touch) |
|
Backlight MTBF (@25°C Ambient) |
80,000 hours |
|
Front Panel Protection Grade |
IP65 / NEMA 4X |
|
Rear Enclosure Protection Grade |
IP20 |
| CPU & Cooling System |
Cooling Method |
Fanless fully passive heat dissipation, maintenance-free |
|
Processor Chip |
Intel Atom X6413E (4 Cores / 4 Threads) |
|
CPU Clock Frequency |
Base 1.5 GHz, Burst up to 2.2 GHz, 2 MB L2 Cache |
|
Onboard Hardware |
Integrated Intel UHD Graphics + TPM 2.0 security chip |
| Memory & Storage |
System RAM |
4 GB DDR4 3200 SDRAM, expandable max 16 GB |
|
Internal Storage Drive |
240 GB industrial SATA SSD (Code W) |
|
External Storage Expansion |
M.2 Key B slot for data logging & expansion modules |
| Hardware Interfaces |
Ethernet Communication |
3 × Gigabit RJ45 (10/100/1000 Mbps, PROFINET & TSN compliant) |
|
USB Ports |
4 × USB3.1 Gen2 (rear panel); 1 × front service USB2.0 port |
|
Serial COM Port |
No onboard COM port (0 suffix in mid segment) |
|
External Video Output |
2 × DisplayPort for multi-monitor expansion |
| Operating System Configuration |
OS Version |
Windows 10 IoT Enterprise 2019 LTSC, Single English Language, 64-bit |
|
Pre-installed Runtime Software |
WinCC RT Advanced V18 Runtime (Code B, unlimited process tags) |
| Power Supply Specifications |
Rated Input Voltage |
24 V DC; allowable tolerance range: 19.2 V ~ 28.8 V DC |
|
Max Full-Load Power Consumption |
42 W |
| Mechanical Dimensions |
Front Panel Overall Size (W × H) |
392 mm × 302 mm |
|
Total Device Depth |
76 mm |
|
Panel Mount Cutout Size (W × H) |
372 mm × 282 mm |
|
Approximate Net Weight |
3.1 kg |
| Environmental Operating Ratings |
Continuous Vertical Operating Temperature |
0 °C ~ +50 °C |
|
Storage & Transportation Temperature |
-20 °C ~ +60 °C |
|
Ambient Relative Humidity |
5% ~ 90% RH, non-condensing environment only |
|
Vibration Resistance Standard |
Compliant with IEC 60068-2-6 industrial test standard |
|
Shock Resistance Standard |
Compliant with IEC 60068-2-27 industrial test standard |
| Global Certification & Export Info |
Official Certifications |
CE, cULus, UKCA, RoHS 3 compliant |
|
Export Control Classification Number (ECCN) |
5A992 |
