6AV7882-0AA10-0AA0 English Technical Parameter Table
| Item | Parameter Value |
|---|---|
| MLFB Order Number | 6AV7882-0AA10-0AA0 |
| Product Series | SIMATIC IPC277E Nanopanel Industrial Panel PC |
| Display | 7″ TFT, 800×480 WVGA, analog resistive single touch |
| Front Protection Rating | IP65 / NEMA 4X |
| Rear Housing Protection | IP20 |
| Backlight MTBF @25°C | 80,000 hours |
| Cooling Structure | Fanless passive cooling |
| Processor | Intel Celeron N2807, 2 Cores / 2 Threads |
| CPU Clock | Base 1.58 GHz, Burst 2.16 GHz, L2 Cache 1 MB |
| Integrated Graphics | Intel HD Graphics |
| System RAM | 2 GB DDR3L (max expandable to 8 GB) |
| Internal Storage | No built-in SSD, only CFast card slot for storage |
| Expansion Slot | CFast card slot for data logging & backup |
| Ethernet Interfaces | 2 × RJ45 Gigabit Ethernet (10/100/1000 Mbps, PROFINET compliant) |
| USB Ports | 1 × USB3.0 (rear); 2 × USB2.0 (1 rear + 1 front service port) |
| Serial Interface | 1 × COM1, configurable RS232 / RS422 / RS485 |
| External Video Output | 1 × DisplayPort |
| Operating System | Without pre-installed operating system |
| Pre-installed SIMATIC Runtime Software | None |
| Rated Power Input | 24 V DC, tolerance range 19.2 V ~ 28.8 V DC |
| Max Power Consumption (Full Load) | 26 W |
| Front Panel Dimension (W × H) | 214 mm × 158 mm |
| Overall Depth | 77 mm |
| Panel Mount Cutout (W × H) | 197 mm × 141 mm |
| Approximate Net Weight | 1.5 kg |
| Vertical Operating Temperature | 0 °C ~ +50 °C |
| Storage & Transport Temperature | -20 °C ~ +60 °C |
| Ambient Humidity | 5% ~ 90% RH, non-condensing |
| Vibration Compliance | IEC 60068-2-6 |
| Shock Compliance | IEC 60068-2-27 |
| Certifications | CE, cULus, UKCA, RoHS |
| ECCN Export Control Code | 5A992 |
| Country of Origin | Germany |
| Lifecycle Status | Discontinued product |
