6AV7882-0ED60-6DA0 English Technical Parameter Table
| Item | Parameter Value |
|---|---|
| MLFB Order Number | 6AV7882-0ED60-6DA0 |
| Product Series | SIMATIC IPC277E Nanopanel Industrial Panel PC |
| Display | 19″ TFT, 1280×1024 SXGA, Capacitive Multi-Touch Screen |
| Front Protection Grade | IP65 / NEMA 4X |
| Rear Housing Protection | IP20 |
| Backlight MTBF (25°C) | 80,000 hours |
| Cooling Mode | Fanless passive cooling |
| Processor | Intel Celeron N2930, 4 Cores / 4 Threads, with TPM |
| CPU Clock | Base 1.83 GHz, Burst 2.16 GHz, L2 Cache 2 MB |
| Integrated Graphics | Intel HD Graphics |
| System RAM | 8 GB DDR3L with NVRAM (non-volatile memory) |
| Internal Storage | 256 GB Industrial SATA SSD (replaceable) |
| Expansion Slot | CFast card slot for data logging & backup |
| Ethernet Ports | 2 × RJ45 Gigabit Ethernet (10/100/1000 Mbps, PROFINET compliant) |
| USB Interfaces | 1 × USB3.0 (rear); 3 × USB2.0 (2 rear + 1 front service port) |
| Serial Port | 1 × COM1, configurable RS232 / RS422 / RS485 |
| External Video Output | 1 × DisplayPort |
| Operating System | Windows 10 IoT Enterprise 64-bit, Single English Language |
| Pre-installed SIMATIC Runtime Software | None |
| Rated Input Power | 24 V DC, tolerance range 19.2 V ~ 28.8 V DC |
| Max Power Consumption (Full Load) | 49 W |
| Front Panel Dimension (W × H) | 444 mm × 344 mm |
| Overall Depth | 78 mm |
| Panel Mount Cutout (W × H) | 424 mm × 324 mm |
| Approximate Net Weight | 4.2 kg |
| Vertical Operating Temperature | 0 °C ~ +50 °C |
| Storage & Transport Temperature | -20 °C ~ +60 °C |
| Ambient Humidity | 5% ~ 90% RH, non-condensing |
| Vibration Compliance | IEC 60068-2-6 |
| Shock Compliance | IEC 60068-2-27 |
| Certifications | CE, cULus, UKCA, RoHS |
| Export Control Code | ECCN 5A992 |
| Country of Origin | Germany |
| Lifecycle Status | PM400, Phase-out announced since 31.07.2025 |
