6ES7647-8BB51-0RA0 Technical Specifications
Product Family: SIMATIC IPC227E (Nanobox PC)
Article Number: 6ES7647-8BB51-0RA0
| Category | Parameter | Specification |
|---|---|---|
| General | Product type | SIMATIC IPC227E Nanobox Industrial PC |
| Design | Box PC, built-in unit | |
| Mounting | DIN rail, wall mounting, portrait mounting | |
| Processor | Processor type | Intel Celeron N2930 (4 cores / 4 threads) |
| Chipset | SoC (System on Chip) | |
| Memory | Memory type | DDR3L SO-DIMM |
| Main memory | 4 GB (with NVRAM) | |
| Max. memory capacity | 8 GB | |
| Retentive data area | 512 KB max. (128 KB buffered, optional) | |
| Storage | CFast slot | 1× CFast (8 GB CFast included) |
| 2.5″ SATA HDD | ≥ 320 GB (optional) | |
| SSD | 256 Eco / 240 / 480 GB (optional) | |
| Graphics | Graphics controller | Integrated (Intel HD Graphics) |
| Video interface | 1× DisplayPort | |
| Interfaces | Industrial Ethernet | 2× RJ45, 10/100/1000 Mbit/s |
| USB | 1× USB 3.0 + 3× USB 2.0 | |
| Serial interface | Without COM ports | |
| Keyboard/Mouse | USB / USB | |
| Expansion | PCIe slot | 1× PCIe x1 (optional) |
| CompactFlash slot | 1× CFast | |
| Power Supply | Supply voltage | 24 V DC |
| Mains buffering | 20 ms hold-up time | |
| Integrated Functions | Temperature monitoring | Yes |
| Watchdog | Yes | |
| Status LEDs | 1× power, 3× user-defined | |
| Cooling | Fanless (passive cooling) | |
| Network monitoring | Optional | |
| Environmental | Operating temperature | 0 °C to +60 °C (-20 °C optional) |
| Storage/transport temperature | -20 °C to +60 °C | |
| Relative humidity | 5% to 85% (operation, no condensation) | |
| Vibration resistance | 10–58 Hz: 0.075 mm; 58–200 Hz: 1 g (IEC 60068-2-6) | |
| Shock resistance | 150 m/s², 11 ms (IEC 60068-2-27) | |
| IP rating | IP40 (front and rear) | |
| Dust protection | Protection against foreign bodies > 1 mm | |
| EMC / Approvals | CE mark | Yes |
| UL / cULus | Yes (UL 508) | |
| RCM (C-TICK) | Yes | |
| KC approval | Yes | |
| FCC | Class A | |
| EMC standards | EN 61000-6-2, EN 61000-6-4 | |
| Marine approvals | GL, ABS, BV, DNV, KRS, LRS, NK, CCS | |
| Hazardous area | ATEX/IECEx Zone 2 (optional) | |
| Operating System | Pre-installed OS | Without operating system |
| Supported OS | Windows 7 Ultimate 32/64-bit
Windows Embedded Standard 7 Windows 10 IoT Enterprise 2016 LTSB 64-bit Windows 10 IoT Enterprise 2019 LTSC 64-bit SIMATIC Industrial OS (optional) |
|
| Software Options | SIMATIC software | WinCC RT Advanced / Software Controller CPU 1500S (optional bundle) |
| Dimensions | Width | 191 mm |
| Height | 100 mm | |
| Depth | 60 mm |
