6SL3310-1TE35-0AB3
GG +/FSG/AC-AC/480V/250kW/ 490A DAC
| Parameter | Specification |
|---|---|
| Part Number | 6SL3310-1TE35-0AB3 |
| Product Line | SINAMICS S120 Power Module (Chassis, PM330) |
| Input Voltage | 3‑phase AC 380–480 V (±10%, −15% < 1 min); 342–528 V operating range |
| Input Frequency | 47–63 Hz (50/60 Hz nominal) |
| Rated Output Power (LO) | 250 kW |
| Rated Output Power (HO) | 200 kW |
| Rated Output Current (LO) | 490 A |
| Peak Current | 735 A (1.5 × In, 60 s / 300 s cycle) |
| Output Frequency Range | 0–550 Hz |
| DC Link Voltage | Approx. 1.35 × input voltage |
| Cooling Method | Internal air cooling with integrated fan |
| Protection Class | IP20 (cabinet mounting) |
| Dimensions (W × H × D) | 326 mm × 1533 mm × 545 mm |
| Net Weight | 140.00 kg |
| Control Interfaces | 3 × DRIVE‑CLiQ; compatible with CU310‑2 / CU320‑2 / SIMOTION D |
| Rectifier Type | 6‑pulse, non‑regenerative |
| Safety Compliance | IEC 61508 (SIL2), EN ISO 13849‑1 (PLd) |
| Operating Ambient Temperature | 0–40 °C; derated up to 50 °C |
| Max. Operating Altitude | 1000 m above sea level (without derating) |
| Relative Humidity | ≤80 %, non‑condensing |
| Efficiency | 97.8% |
| Sound Pressure Level (1 m) | 75 dB |
| Power Loss | 5.5 kW |
| Certifications | CE, UL, cUL, RoHS |
| Special Feature | Conformal coating for harsh industrial environments |
