6FX2001-5QE13
| Product Type | Absolute encoder (Singleturn) |
| Part Number | 6FX2001-5QE13 |
| Operating Voltage | Up DC 5 V ± 5% |
| Current Consumption | Approx. 160 mA |
| Interface | EnDat 2.1 |
| Resolution | 13 bit / 8192 Steps per revolution |
| Incremental Track | 512 S/R, 1 Vpp |
| Code Type | Gray code (Sampling), Binary (Transmission) |
| Electrical Connection | M23 flange socket, Radial |
| Shaft Type | Solid shaft / Strip flange |
| Shaft Diameter | 10 mm |
| Shaft Length | 20 mm |
| Max. Mechanical Speed | 6000 rpm (Mechanical) / 12000 rpm (with reduced accuracy) |
| Operating Temperature | -40 … +100 °C |
| Degree of Protection | IP67 (without shaft input) / IP64 (with shaft input) |
| Vibration Resistance | 300 m/s² (55…2000 Hz per EN 60068-2-6) |
| Shock Resistance | 1,000 m/s² (6 ms per EN 60068-2-27) |
| Compliance | CE, cULus |
| Weight | Approx. 0.4 kg |
