6FX2001-5QS12
| Parameter | Specification |
| Product Description | ABSOLUTE VALUE ENCODER SINGLETURN 13 BIT WITH SSI, OPERAT. VOLT. 10-30 V STRIP FLANGE SHAFT 10MM RADIAL FLANGE SOCKET |
| Product Family | Absolute encoders with SSI |
| Lifecycle | PM300: Active Product |
| Electrical Specifications | |
| Encoder Type | Singleturn absolute encoder |
| Interface | SSI (Synchronous Serial Interface) |
| Resolution | 13 bit (8192 steps per revolution) |
| Operating Voltage | 10 – 30 V DC |
| Current Consumption | Approx. 160 mA |
| Code Type | Gray code |
| Electrical Connection | M23 flange socket, radial |
| Transmission Standard | RS485 (Differential line receiver/driver) |
| Mechanical Specifications | |
| Shaft Type | Solid shaft / Strip flange |
| Shaft Diameter | 10 mm |
| Shaft Length | 20 mm |
| Maximum Mechanical Speed | 12000 rpm |
| Starting / Friction Torque (20°C) | ≤ 0.01 Nm |
| Rotor Moment of Inertia | 0.00000145 kgm² |
| Weight | Approx. 0.400 kg |
| Environmental Specifications | |
| Degree of Protection | IP67 (housing) / IP64 (shaft input) |
| Operating Temperature | -40 to +85 °C |
| Vibration Resistance | 300 m/s² (EN 60068-2-6) |
| Shock Resistance | 1000 m/s², 6 ms (EN 60068-2-27) |
| Logistics & Classification | |
| Article Number (MLFB) | 6FX2001-5QS12 |
| Commodity Code | 90314990 |
| Country of Origin | Germany |
