7MB2338-4AK16-3NG1
| Order Number | 7MB2338-4AK16-3NG1 |
| Product Family | ULTRAMAT 23 |
| Product Type | Gas Analyzer |
| Measurement Capability | 3 infrared components + oxygen concentration |
| Mounting Type | 19″ plug‑in unit for mounting in cabinets |
| Gas Connections | 6 mm tube |
| Internal Sample Gas Pump | Without internal sample gas pump |
| Gas Paths | With separate gas paths (2 channels) |
| 1st Component Measured | CO (carbon monoxide) |
| CO – Min. Measuring Range | 0 to 250 mg/m³ |
| CO – Max. Measuring Range | 0 to 1250 mg/m³ |
| 2nd Component Measured | NO (nitric oxide) |
| NO – Min. Measuring Range | 0 to 400 mg/m³ |
| NO – Max. Measuring Range | 0 to 2000 mg/m³ |
| O₂ Sensor | With O₂ sensor |
| 3rd Component Measured | SO₂ (sulfur dioxide) |
| SO₂ – Min. Measuring Range | 0 to 200 vpm |
| SO₂ – Max. Measuring Range | 0 to 1000 vpm |
| Power Supply | AC 230 V, 50 Hz |
| Operator Software / Documentation | Operator’s software and documentation in English |
| Net Weight | 12.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | France |
