6FX2001-3CB02
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Product Description | Incremental encoder with 1-V-sinus 1024 p/r, Synchro flange, 6 mm shaft, operating voltage 5 V, axial/radial universal cable outlet, cable 1 m with connector |
| Product Family | Incremental encoders with sin/cos 1 Vpp |
| Part Number | 6FX2001-3CB02 (also listed as 6FX20013CB02) |
| Encoder Type | Incremental (Optoelectronic scanning principle) |
| Pulses per Revolution (PPR) | 1024 |
| Output Signal Level | 1 Vpp (sin/cos) |
| Shaft Diameter | 6 mm |
| Flange Design | Synchro flange |
| Supply Voltage | 5 VDC |
| Maximum Current Consumption | 150 mA |
| Scanning Frequency | 200 kHz |
| Cable Length | 1 meter (with connector) |
| Cable Outlet | Universal (axial / radial) |
| Protection Class | IP64 |
| Maximum Operating Temperature | 100 °C |
| Net Weight | Approx. 0.50 kg (1.102 lbs) |
| Product Lifecycle (PLM) | PM300 (Active product) |
| Country of Origin | Germany |
