6AV7892-0AB00-1AB0
***No longer available*** SIMATIC HMI IPC677C (Panel PC), 2×10/100/1000 Mbit/s Ethernet; 4 x USB V2.0, 1x serial (COM1); Watchdog, temperature and fan monitoring; RAID controller onboard; 15″ Touch; 1024x 768 with front-side USB-Schnittstelle 24 V DC power supply Celeron P4505 (2C/2T, 1.86 GHz, 2 MB cache); PROFIBUS/MPI (CP 5611-A2-compatible); 2 MB buffered SRAM 1 GB DDR3 1066 DIMM; 250 GB HDD SATA DVD+-R+-RW; 2x PCI free Windows XP Prof. SP3 MUI (de, en, fr, es, it) without expansion (software)
| Order Number | 6AV7892-0AB00-1AB0 |
| Product Name | SIMATIC HMI IPC677C (Panel PC) |
| Ethernet Interfaces | 2 x 10/100/1000 Mbit/s |
| USB Interfaces | 4 x USB V2.0 |
| Serial Interface | 1 x serial (COM1) |
| Monitoring Functions | Watchdog; temperature and fan monitoring |
| Storage Controller | RAID controller (onboard) |
| Display | 15″ Touchscreen; 1024 x 768 resolution |
| Front-Side Interface | Front-side USB interface |
| Power Supply | 24 V DC |
| Processor | Intel Celeron P4505 (2 cores / 2 threads, 1.86 GHz, 2 MB cache) |
| Fieldbus Interface | PROFIBUS/MPI (CP 5611-A2-compatible) |
| Buffered Memory | 2 MB buffered SRAM |
| RAM | 1 GB DDR3 1066 DIMM |
| Hard Disk Drive | 250 GB HDD SATA |
| Optical Drive | DVD±R±RW |
| Expansion Slots (Free) | 2 x PCI (free) |
| Operating System | Windows XP Professional SP3 MUI (languages: German, English, French, Spanish, Italian) |
| Additional Software | Without expansion (software) |
| warranty | 1 YEAR |
| Net Weight (kg) | 17,450 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
