6AV7882-0BB50-2BD0
SIMATIC IPC277E (Nanopanel PC); 9″ Touch TFT; 2x 10/100/1000 Mbps Ethernet RJ45; 1x display port graphic; 1x USB 3.0; 2x USB 2.0; 1x serial (COM 1); CFast slot; 24 V DC power supply Celeron N2930 (4C/4T) 4 GB with NVRAM WIN Embedded Standard 7E SP1, English; 64 bit 80 GB SSD; WinCC RT Advanced V16 Update 1, 128 PT;
| Order Number | 6AV7882-0BB50-2BD0 |
| Product Designation | SIMATIC IPC277E (Nanopanel PC) |
| Display | 9″ Touch TFT |
| Ethernet Interfaces | 2x 10/100/1000 Mbps Ethernet RJ45 |
| Graphic Interface | 1x DisplayPort |
| USB Interfaces | 1x USB 3.0; 2x USB 2.0 |
| Serial Interface | 1x Serial (COM 1) |
| Storage Slot | CFast Slot |
| Power Supply | 24 V DC |
| Processor | Intel Celeron N2930 (4 Cores / 4 Threads) |
| Memory (RAM) | 4 GB, with NVRAM |
| Operating System | Windows Embedded Standard 7E SP1, English (64-bit) |
| Mass Storage | 80 GB SSD |
| Preinstalled Runtime Software | WinCC RT Advanced V16 Update 1, 128 Power Tags (PT) |
| warranty | 1 YEAR |
| Net Weight (kg) | 1,950 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
