6AG4104-3HA12-2XX6
SIMATIC IPC547E (rack PC, 19″, 4HU); Interfaces: 2x USB 3.0 front, 1x DVI-I, 6x USB 2.0 on the rear side, 2x PS/2, audio; 7 slots: 2x PCIe X16, 1x PCIE X8, 4x PCI; temperature and fan monitoring; Watchdog; card retainer Core I5-4570S (4C/4T, 2.9(3.6) GHz, 6 MB cache, IAMT), 2x Gbit Ethernet, 2x display ports V1.2, 2x USB 3.0 on the rear side, 1x USB 2.0 internal, 1x COM1 1x 500 GB HDD, internal 2 GB DDR3 SD-RAM (1x 2 GB), Single channel Enclosure painted, DVD +/-RW (SLIM) Serial (COM2)+parallel (LPT) Graphics onboard without operating system without expansions (software) 2x 100/240V AC redundant industrial power supply unit; without line cable
| Product | |
| Article Number (Market Facing Number) | 6AG4104-3HA12-2XX6 |
| Product Description | SIMATIC IPC547E (rack PC, 19″, 4HU); Interfaces: 2x USB 3.0 front, 1x DVI-I, 6x USB 2.0 on the rear side, 2x PS/2, audio; 7 slots: 2x PCIe X16, 1x PCIE X8, 4x PCI; temperature and fan monitoring; Watchdog; card retainer Core I5-4570S (4C/4T, 2.9(3.6) GHz, 6 MB cache, IAMT), 2x Gbit Ethernet, 2x display ports V1.2, 2x USB 3.0 on the rear side, 1x USB 2.0 internal, 1x COM1 1x 500 GB HDD, internal 2 GB DDR3 SD-RAM (1x 2 GB), Single channel Enclosure painted, DVD +/-RW (SLIM) Serial (COM2)+parallel (LPT) Graphics onboard without operating system without expansions (software) 2x 100/240V AC redundant industrial power supply unit; without line cable |
| Product family | SIMATIC IPC847E |
| Rack PC, 19″, 4HU | |
| Processor type/CPU | Core I5-4570S |
| Memory capacity | 2 GB |
| Harddisk | 1x 500 GB |
| Operating system/OS | Without |
| Network Interface | 2x Gbit Ethernet, 2x display ports V1.2, 2x USB 3.0 on the rear side, 1x USB 2.0 internal |
| Other Interface | 2x USB 3.0 front, 1x DVI-I, 6x USB 2.0 on the rear side, 2x PS/2, audio; 7 slots: 2x PCIe X16, 1x PCIE X8, 4x PCI; temperature and fan monitoring; Watchdog |
| Power supply | 2x 100/240V AC |
| Warranty | 1 Year |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84715000 |
| LKZ_FDB/ CatalogID | IC10-A |
| Product Group | 4343 |
| Group Code | R133 |
