6AG4104-4DA02-3XX0
SIMATIC IPC547G (Rack PC, 19″, 4HU); Interfaces: 2x USB 3.0 on the front; 2x Intel Gigabit Ethernet, 2x PS/2, Audio on the rear side; 7 slots: 5x PCI Express, 2x PCI, Temperature and Fan monitoring; Watchdog; Card retainer Core i7-6700 (4C/8T, 3.4 (4.0) GHz, 8 MB cache); Mainboard: (chipset H110, 1x DVI-D, 1x display port V1.2, 2x USB 3.0 and 4x USB 2.0 on the rear side) 1x 1 TB HDD, internal, (0.2 g vibration, 1 g shock) 4 GB DDR4 SD-RAM (1x 4 GB), Single channel Enclosure blue chromated, 100/240V AC industrial power supply unit, DVD +/-RW (slim) Serial (COM2)+parallel (LPT) Graphics onboard Without operating system without expansions (software) without line cable
| Order Number | 6AG4104-4DA02-3XX0 |
| Product Designation | SIMATIC IPC547G (Rack PC, 19″, 4HU) |
| Front Interfaces | 2x USB 3.0 |
| Rear Interfaces | 2x Intel Gigabit Ethernet, 2x PS/2, Audio |
| Expansion Slots (Total) | 7 slots: 5x PCI Express, 2x PCI |
| Monitoring Features | Temperature and Fan monitoring; Watchdog; Card retainer |
| Processor | Core i7-6700 (4C/8T, 3.4 (4.0) GHz, 8 MB cache) |
| Motherboard | Chipset H110; 1x DVI-D, 1x DisplayPort V1.2, 2x USB 3.0 (rear), 4x USB 2.0 (rear) |
| Hard Disk Drive (HDD) | 1x 1 TB, internal (Shock: 1 g; Vibration: 0.2 g) |
| Memory (RAM) | 4 GB DDR4 SD-RAM (1x 4 GB), Single channel |
| Enclosure Finish | Blue chromated |
| Power Supply | 100/240V AC industrial power supply unit |
| Optical Drive | DVD +/-RW (slim) |
| Legacy Ports | Serial (COM2) + Parallel (LPT) |
| Graphics | Onboard (integrated) |
| Operating System | Without operating system |
| Pre-installed Software | Without expansions (software) |
| Accessories | Without line cable |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
