6AG4104-4JF24-1GX1
SIMATIC IPC547G (Rack PC, 19″, 4HU); Interfaces: 2x USB 3.0 on the front; 2x Intel Gigabit Ethernet, 2x PS/2, Audio on the rear side; 7 slots: 5x PCI Express, 2x PCI, Temperature and Fan monitoring; Watchdog; Card retainer Xeon E3-1275 v5 (4C/8T, 3.6 (4.0) GHz, 8 MB cache, iAMT); Mainboard: (chipset C236, 1x DVI-D, 2x display ports V1.2, 4x USB 3.0 and 4x USB 2.0 on the rear side, 1x USB 2.0 internal, 1x COM 1; RAID onboard) RAID1, 1 TB (2x 1 TB HDD) internal (0.2 g vibration, 1 g shock) 16 GB DDR4 SD-RAM (2x 8 GB), Dual Channel Enclosure blue chromated, 2x 100/240V AC redundant Industrial power supply unit, DVD +/-RW (slim) Graphics onboard; Adapter cable DP According to VGA for onboard graphic Windows Server 2012 R2 Standard edition incl. 5 clients, MUI (en/de/fr/it/es), 64 bit without expansions (software) Power supply cable Europe
| Order Number | 6AG4104-4JF24-1GX1 |
| Product Designation | SIMATIC IPC547G (Rack PC, 19″, 4HU) |
| Front Interfaces | 2x USB 3.0 |
| Rear Interfaces | 2x Intel Gigabit Ethernet, 2x PS/2, Audio |
| Expansion Slots (Total) | 7 slots: 5x PCI Express, 2x PCI |
| Monitoring Functions | Temperature and Fan monitoring, Watchdog, Card retainer |
| Processor | Intel Xeon E3-1275 v5 (4C/8T, 3.6 (4.0) GHz, 8 MB cache, iAMT) |
| Motherboard | Chipset C236; 1x DVI-D, 2x DisplayPort V1.2, 4x USB 3.0 (rear), 4x USB 2.0 (rear), 1x USB 2.0 (internal), 1x COM 1; RAID onboard |
| RAID Configuration | RAID1 |
| Internal Storage | 1 TB (2x 1 TB HDD) |
| Shock & Vibration Tolerance (Storage) | 0.2 g (vibration), 1 g (shock) |
| Memory (RAM) | 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel |
| Chassis Finish | Blue chromated enclosure |
| Power Supply | 2x 100/240V AC redundant Industrial power supply unit |
| Optical Drive | DVD+/-RW (slim) |
| Graphics | Onboard graphics; Adapter cable DP-to-VGA for onboard graphic |
| Operating System | Windows Server 2012 R2 Standard Edition, incl. 5 clients, MUI (EN/DE/FR/IT/ES), 64-bit, without expansions (software) |
| Accessories Included | Power supply cable (Europe) |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
