6AG4104-5JG13-2AX0
SIMATIC IPC547J (rack PC, 19″, 4 U); interfaces: 2x USB 3.0 on the front; COM1, audio on the rear side; 7 slots: 5x PCI Express, 2x PCI, temperature and fan monitoring; watchdog; card retainer Core i7-10700E (8C/16T, 2.9 (4.5) GHz, 16 MB cache), mainboard (chipset W480E, 3x Gbit Ethernet, 1x DVI-D, 2x DisplayPort, 6x USB 3.1 Gen.2, 2x USB 2.0 internal, AMT), RAID1, 2x 1 TB HDD 3.5 SATA, enclosure with drive support type B (for internal installation/ 0.2 g vibration, 2 g shock), blue chromated, 100/240 V AC industrial power supply unit, power supply cable China, 16 GB DDR4 SDRAM (2x 8 GB), dual channel, without expansion, without operating system, without expansions,
| Order Number | 6AG4104-5JG13-2AX0 |
| Product Designation | SIMATIC IPC547J (Rack PC, 19″, 4 U) |
| Front Interfaces | 2× USB 3.0 |
| Rear Interfaces | COM1, Audio |
| Expansion Slots (Total) | 7 slots: 5× PCI Express, 2× PCI |
| Monitoring Features | Temperature and fan monitoring; Watchdog |
| Mechanical Retention | Card retainer |
| Processor | Intel Core i7-10700E (8 cores / 16 threads, base frequency 2.9 GHz, turbo frequency 4.5 GHz, 16 MB cache) |
| Motherboard / Chipset | Chipset W480E; onboard I/O: 3× Gbit Ethernet, 1× DVI-D, 2× DisplayPort, 6× USB 3.1 Gen.2 (external), 2× USB 2.0 (internal); Intel AMT support |
| Storage Configuration | RAID1 (mirrored); 2× 1 TB HDD, 3.5″ form factor, SATA interface |
| Chassis / Drive Support | Enclosure with drive support type B (qualified for internal installation; vibration resistance: 0.2 g; shock resistance: 2 g) |
| Surface Treatment | Blue chromated |
| Power Supply | 100/240 V AC industrial power supply unit |
| Power Cable | China-specific power supply cable |
| Memory (RAM) | 16 GB DDR4 SDRAM (2× 8 GB modules), dual-channel configuration |
| Pre-installed Operating System | None (without operating system) |
| Additional Expansions | None (without expansions) |
| warranty | 1 YEAR |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
