6AG4104-5KB41-0BX0
| Order No. | 6AG4104-5KB41-0BX0 |
| Product Name | SIMATIC IPC547J (rack PC, 19″, 4 U) |
| Front Interfaces | 2x USB 3.0 |
| Rear Interfaces | COM1, audio |
| Expansion Slots | 7 slots total: 5x PCI Express, 2x PCI |
| Monitoring Features | Temperature and fan monitoring; watchdog |
| Additional Hardware | Card retainer |
| Processor | Core i9-10900E (10C/20T, 2.8 (4.7) GHz, 20 MB cache) |
| Mainboard / Chipset | Chipset W480E, 3x Gbit Ethernet, 1x DVI-D, 2x DisplayPort, 6x USB 3.1 Gen.2, 2x USB 2.0 internal, AMT |
| Storage | 2x 1 TB HDD 3.5″ SATA |
| Enclosure | Enclosure with drive support type A (for rack units on the front), painted |
| Power Supply | 100/240 V AC industrial power supply unit |
| Power Cable | Europe type |
| RAM | 4 GB DDR4 SDRAM (1x 4 GB), single channel |
| Additional Interfaces | COM2 interface |
| Operating System | Without operating system |
| Expansions | Without expansions |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 17,00 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
