6AG4112-3DQ62-0JX0
SIMATIC IPC647E (Rack PC, 19″, 2U); 3x Gbit Ethernet (IE/PN), RJ45; 1x DVI-D, 2x displayport, 1x COM1, audio, 4x USB 3.1, 2x USB 3.1 (Typ C) rear side; 2x USB 3.0 front, 1x USB3.1 internally; 1x M.2 Slot internally; temperature and fan monitoring, watchdog; card retainer; Core i5-8500 (6C/6T, 3.0 (4.1) GHz, 9 MB cache,TB, VT-D, AMT); Board 2 slots: 1x PCIe x16 (16 L), 1x PCIe x16 (4 L); 480 GB SSD 2.5″ SATA; Enclosure with drive support Type B (for internal installation/ 0.5 g vibration, 5 g shock); COM2 interface; 2x 100/240V AC redundant industrial power supply unit; 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel; Without expansion (HW); Windows Server 2019 Standard edition including 5 clients, 64-bit, MUI (en, de, fr, it, es); Without expansions; Without power supply cable
| Article Number (Market Facing Number) | 6AG4112-3DQ62-0JX0 |
| Product family | SIMATIC IPC647E |
| Product Type | Rack PC, 19″, 2U |
| Rear I/O Interfaces | – 3x Gbit Ethernet (IE/PN), RJ45 |
| – 1x DVI-D | |
| – 2x DisplayPort | |
| – 1x COM1 (serial) | |
| – Audio ports | |
| – 4x USB 3.1 (Type-A) | |
| – 2x USB 3.1 (Type-C) | |
| Front I/O Interfaces | 2x USB 3.0 (Type-A) |
| Internal I/O Interfaces | – 1x USB 3.1 (internal) |
| – 1x M.2 slot (internal) | |
| Monitoring & Safety | – Temperature and fan monitoring |
| – Watchdog | |
| – Card retainer (for expansion cards) | |
| Processor | Intel Core i5-8500 (6 cores / 6 threads, base 3.0 GHz, turbo 4.1 GHz, 9 MB cache, supports Turbo Boost, VT-D, AMT) |
| Motherboard / Slots | Board with 2 slots: |
| – 1x PCIe x16 (electrical x16) | |
| – 1x PCIe x16 (electrical x4) | |
| Storage | 480 GB SSD, 2.5″ SATA form factor |
| Chassis / Mechanical | Enclosure with drive support Type B |
| (suitable for internal installation; vibration resistance: 0.5 g; shock resistance: 5 g) | |
| Additional Interface | COM2 interface (second serial port) |
| Power Supply | 2x 100/240V AC redundant industrial power supply unit |
| Memory (RAM) | 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel |
| Expansion (Hardware) | Without expansion (HW) – no additional factory-installed hardware options |
| Pre-installed OS | Windows Server 2019 Standard Edition |
| Includes 5 client access licenses | |
| 64-bit | |
| MUI (Multi‑language User Interface: English, German, French, Italian, Spanish) | |
| Optional Expansions | Without expansions (no additional options selected) |
| Accessories | Without power supply cable |
| warranty | 1 YEAR |
| Net Weight (kg) | 14,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
