6AV7260-5GH31-0BX6
SIMATIC IPC677D (Panel PC), 2×10/100/1000 Mbit/s Ethernet; 4x USB V3.0, 1x serial (COM1); Watchdog, temperature and Fan monitoring; RAID controller onboard; 22″ Multitouch (1920x 1080) XEON E3-1268LV3 (4C/8T, 2.3 (3.3) GHz, 8 MB cache VT-D, AMT) RAID1 2x 320 GB SATA (2.5″); DVD +/-RW 8 GB DDR3 1600 DIMM; 1x PCIE (X16); 1x PCI without expansion (HW) Windows 7 Ultimate 64 bit SP1, MUI (de, en, fr, es, it) without expansion (software) 24 V DC industrial Power supply
| Order Number | 6AV7260-5GH31-0BX6 |
| Product Family | SIMATIC IPC677D (Panel PC) |
| Product Type | Industrial Panel PC |
| Ethernet Interfaces | 2 × 10/100/1000 Mbit/s Ethernet |
| USB Interfaces | 4 × USB V3.0 |
| Serial Interface | 1 × serial (COM1) |
| System Monitoring | Watchdog timer, temperature and fan monitoring |
| Storage Controller | RAID controller onboard |
| Display | 22″ Multitouch (1920 × 1080) |
| Processor | Intel Xeon E3‑1268LV3 (4 cores / 8 threads, 2.3 GHz base / 3.3 GHz turbo, 8 MB cache, VT‑d, AMT) |
| Storage Configuration | RAID1: 2 × 320 GB SATA HDD (2.5″ form factor) |
| Optical Drive | DVD ± RW |
| System Memory (RAM) | 8 GB DDR3 1600 DIMM |
| Expansion Slots | 1 × PCIe (x16), 1 × PCI (both free / available) |
| Hardware Expansions | Without additional hardware expansions (base configuration only) |
| Operating System | Windows 7 Ultimate 64‑bit SP1 MUI (Multilingual User Interface) – supported languages: German, English, French, Spanish, Italian |
| Pre‑installed Software | No additional expansion software included (base configuration only) |
| Power Supply | 24 V DC industrial power supply |
| Net Weight | 17.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | Germany |
