| Order No. | 6ES7660-4DB11-1AD4 |
| Product Name | SIMATIC PCS 7 |
| Industrial Workstation IPC547E | |
| Chassis Type | Rack PC, 19″, 4HU |
| Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port, 1x COM, 2x PS/2, Audio, 2x USB 3.0 (rear), 6x USB 2.0 (rear), 2x USB 3.0 (front), 1x USB 2.0 (internal) |
| Slots | 7 slots total: 2x PCIe x16, 1x PCIe x8, 4x PCI |
| Monitoring & Mechanical | Temperature and fan monitoring (Watchdog); card retainer |
| Processor | Core i5-4570S (4C/4T, 2.9 (3.6) GHz), 6 MB cache, IAMT |
| Configuration | ES/OS Single Station |
| Storage | 1x 1 TB HDD SATA internal |
| Shock & Vibration | 0.2 G vibration, 1 G shock |
| Memory (RAM) | 8 GB DDR3 SDRAM (2x 4 GB), Dual Channel |
| Industrial Ethernet | CP1623 |
| Pre-installed Software | PCS 7 V8.1 SP1 |
| Operating System | Windows 7 Ultimate, 64-bit, MUI (en/de/fr/it/es/cn) |
| Enclosure Finish | Unpainted |
| Optical Drive | DVD +/- RW (slim) |
| Power Supply | 110/240V industrial power supply unit; with NAMUR |
| Power Cable | Power supply cable (Italy) |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15.00 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
