6ES7660-5FF28-2BM3
***no longer available*** SIMATIC PCS 7 Industrial Workstation IPC647D; (rack PC, 19″, 2 U), interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0, front-side; 1x USB 3.0 internal; temperature and fan monitoring; watchdog; card retainer; Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT); OS Client; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel; Without additional system bus communication cards; PCS 7 V8.2 SP1 pre-installed Windows 10 IoT Enterprise 2015 LTSB, 64 bit, MUI (en, de, fr, it, es, cn) bus module 4 slots: 1x PCIe x16 (8 lanes); 3x PCIe x16 (4 lanes); DVD +/-RW (slim); + multi monitor with 4 screens PCIe x16 graphics card; 100/240V industrial power supply unit; with NAMUR; power supply cable USA
| Item | Description |
| Order Number | 6ES7660-5FF28-2BM3 |
| Product Name | SIMATIC PCS 7 |
| Industrial Workstation IPC647D | |
| Form Factor | Rack PC, 19″, 2 U |
| Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x DisplayPort, 1x COM, 2x PS/2, audio; 2x USB 3.0 (rear), 2x USB 2.0 (rear), 1x USB 3.0 (front), 1x USB 2.0 (front), 1x USB 3.0 (internal) |
| Monitoring Features | Temperature and fan monitoring, watchdog |
| Additional Hardware Features | Card retainer |
| Processor | Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT) |
| Operating System Client | OS Client |
| Storage (RAID) | RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring) in removable frame, hot-swappable, front-access |
| Memory (RAM) | 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel |
| System Bus Communication Cards | Without additional system bus communication cards |
| Pre-installed Software | PCS 7 V8.2 SP1, Windows 10 IoT Enterprise 2015 LTSB, 64-bit, MUI (en, de, fr, it, es, cn) |
| Bus Module Slots | 4 slots: 1x PCIe x16 (8 lanes); 3x PCIe x16 (4 lanes) |
| Optical Drive | DVD +/-RW (slim) |
| Graphics | Multi-monitor capable with 4 screens; PCIe x16 graphics card |
| Power Supply | 100/240V industrial power supply unit with NAMUR |
| Power Cable | Power supply cable USA |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
