6ES7660-5FF78-3BY3
***no longer available*** SIMATIC PCS 7 Industrial Workstation IPC647D; (rack PC, 19″, 2 U), interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0, front-side; 1x USB 3.0 internal; temperature and fan monitoring; watchdog; card retainer; Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT); OS Client; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; 32 GB DDR3 SDRAM (4 x 8 GB), ECC, dual channel; Without additional system bus communication cards; PCS 7 V9.0 SP2 pre-installed Windows 10 IoT Enterprise 2015 LTSB, 64 bit, MUI (en, de, fr, it, es, cn) bus module 4 slots: 1x PCIe x16 (8 lanes); 3x PCIe x16 (4 lanes); DVD +/-RW (slim); + multi monitor with 4 screens (combined, onboard interfaces (2xDP) + dual head PCIe x16 board (2 x DP)), incl. 1xDP according to DVI-D adapter cable, including 1xdual DVI-I adapter for dual head PCIe x16 board 100/240V industrial power supply unit; with NAMUR; power supply cable USA
| Product Code | 6ES7660-5FF78-3BY3 |
| Product Name | SIMATIC PCS 7 |
| Industrial Workstation IPC647D | |
| Chassis | Rack PC, 19″, 2 U |
| Rear Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x DisplayPort, 1x COM, 2x PS/2, audio, 2x USB 3.0, 2x USB 2.0 |
| Front Interfaces | 1x USB 3.0, 1x USB 2.0 |
| Internal Interfaces | 1x USB 3.0 |
| Monitoring Features | Temperature and fan monitoring, watchdog |
| Mechanical Features | Card retainer |
| Processor | Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT) |
| OS Client | Included |
| Storage (RAID) | RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring) in removable frame, hot swap, front accessible |
| Memory | 32 GB DDR3 SDRAM (4 x 8 GB), ECC, dual channel |
| Communication Cards | None (Without additional system bus communication cards) |
| Pre-installed Software | PCS 7 V9.0 SP2 |
| Operating System | Windows 10 IoT Enterprise 2015 LTSB, 64-bit, MUI (en, de, fr, it, es, cn) |
| Bus Module Slots | 4 slots: 1x PCIe x16 (8 lanes); 3x PCIe x16 (4 lanes) |
| Optical Drive | DVD +/-RW (slim) |
| Multi-Monitor Support | 4 screens (combined: onboard interfaces (2x DP) + dual head PCIe x16 board (2x DP)) |
| Included Adapters | 1x DP to DVI-D adapter cable; 1x dual DVI-I adapter for dual head PCIe x16 board |
| Power Supply | 100/240 V industrial power supply unit with NAMUR |
| Power Cable | USA power supply cable |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
