6ES7660-5GU60-2AK3
| Field | Details |
| Order Number | 6ES7660-5GU60-2AK3 |
| Product Name | SIMATIC PCS 7 |
| Industrial Workstation IPC647D | |
| Form Factor | Rack PC, 19″, 2 U |
| Rear Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port, 1x COM, 2x PS/2, Audio, 2x USB 3.0, 2x USB 2.0 |
| Front Interfaces | 1x USB 3.0, 1x USB 2.0 |
| Internal Interfaces | 1x USB 3.0 |
| Monitoring Features | Temperature and fan monitoring, watchdog |
| Mechanical Features | Card retainer |
| Processor | Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT) |
| System Configuration | ES/OS Single Station |
| Storage | 480 GB SSD (eMLC) SATA in removable frame on front |
| Memory | 16 GB DDR3 SDRAM (2x 8 GB), ECC, dual channel |
| Pre-installed Software | BCE; PCS 7 V8.2 SP1 |
| Operating System | Windows 7 Ultimate, 64-bit, MUI (en/de/fr/it/es/cn) |
| Expansion Slots (Bus Module) | 4 slots: 1x PCIe x16 (8 lane), 3x PCIe x16 (4 lane) |
| Optical Drive | DVD+/-RW (slim) |
| Power Supply | 100/240V industrial power supply unit with NAMUR |
| Power Cable | USA standard |
| Included Accessory | Power supply cable (USA) |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
