6ES7660-5HC70-2DA3
| Item | Description |
| Order No. | 6ES7660-5HC70-2DA3 |
| Product Name | SIMATIC PCS 7 Industrial Workstation IPC647D |
| Form Factor | Rack PC, 19″, 2 U |
| Rear Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x DisplayPort, 1x COM, 2x PS/2, Audio, 2x USB 3.0, 2x USB 2.0 |
| Front Interfaces | 1x USB 3.0, 1x USB 2.0 |
| Internal Interfaces | 1x USB 3.0 |
| Monitoring Features | Temperature and fan monitoring, watchdog |
| Mechanical Features | Card retainer |
| Processor | Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT) |
| Operating System (Server) | OS Server |
| Storage (RAID) | RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring) |
| Shock & Vibration Tolerance | Internal, 0.5 G vibration, 5 G shock |
| Memory (RAM) | 32 GB DDR3 SDRAM (4 x 8 GB), ECC, dual channel |
| BCE | BCE (Bundle Card Ethernet) |
| Pre-installed Software | PCS 7 V8.2 SP1 pre-installed, Windows Server 2008 R2 Standard Edition, 64-bit, MUI (en/de/fr/it/es/cn), incl. 5 clients |
| Expansion Slots (Bus Module) | 4 slots: 2x PCI, 2x PCIe x16 (8 lane) |
| Optical Drive | Without optical drive |
| Power Supply | 100/240V industrial power supply unit with NAMUR |
| Power Cable | Power supply cable USA |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
