6ES7660-5HF11-0DK0
| Item No. | Product Name / Description |
| 6ES7660-5HF11-0DK0 | SIMATIC PCS 7 Industrial Workstation IPC647D (Rack PC, 19″, 2 U) |
| Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x DisplayPort, 1x COM, 2x PS/2, Audio; 2x USB 3.0 (rear), 2x USB 2.0 (rear), 1x USB 3.0 (front), 1x USB 2.0 (front), 1x USB 3.0 (internal) |
| Monitoring & Features | Temperature and fan monitoring; watchdog; card retainer |
| Processor | Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT) |
| Operating System (Server) | OS Server |
| Storage (RAID) | RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring) in removable frame, hot swap, front-side |
| Memory (RAM) | 8 GB DDR3 SDRAM (2 x 4 GB), Dual Channel |
| Industrial Ethernet | CP1623 |
| Pre-installed Software | PCS 7 V8.0 SP2 pre-installed |
| Operating System | Windows Server 2008 R2 Standard Edition incl. 5 clients, 64-bit, MUI (EN/DE/FR/IT/ES/CN) |
| Expansion Slots | Bus module 4 slots: 1x PCIe x16 (8 lane), 3x PCIe x16 (4 lane) |
| Optical Drive | DVD+/-RW (slim) |
| Power Supply | 100/240 V industrial power supply unit with NAMUR |
| Power Cable | Power supply cable (Europe) |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
