6ES7660-6HQ71-1DF6
SIMATIC PCS 7 Industrial Workstation IPC847D; (rack PC, 19″, 4 U), interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0, front-side; 1x USB 3.0 internal; temperature and fan monitoring; watchdog; card retainer; Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT); OS Server; RAID5, 2 TB (3x 1 TB HDD SAS, stripping with parity) in removable frame, hot-swap; on front; PCIE X8 HW-RAID Controller incl. ZMCP module, (2 slots occupied); + 240 GB SSD (EMLC) SATA, in removable frame; on front; 32 GB DDR3 SDRAM (4 x 8 GB), ECC, dual channel; Industrial Ethernet (CP1623); PCS 7 V8.1 SP1 pre-installed; Windows Server 2008 R2 Standard edition incl. 5 clients, 64 bit, MUI (en/de/fr/it/es/cn); bus module 11 slots: 3x PCI, 3x PCIE X4, 5x PCIe x16, DVD +/-RW (slim); + multi monitor with 4 screens PCIe x16 graphics card; 2 x 100/240V redund. power supply unit; without power supply cable
| Field | Details |
|---|---|
| Order Number | 6ES7660-6HQ71-1DF6 |
| Product Description | SIMATIC PCS 7 Industrial Workstation IPC847D; (rack PC, 19″, 4 U) |
| Interfaces | 2x Gbit LAN (RJ45), 1x DVI-I, 2x DisplayPort; 1x COM, 2x PS/2, audio; 2x USB 3.0 (rear), 2x USB 2.0 (rear); 1x USB 3.0 (front), 1x USB 2.0 (front); 1x USB 3.0 (internal) |
| Monitoring & Features | Temperature and fan monitoring; watchdog; card retainer |
| Processor | Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT) |
| Operating System / Server | OS Server |
| Storage (RAID) | RAID5, 2 TB (3x 1 TB HDD SAS, striping with parity) in removable frame, hot-swap (front) |
| RAID Controller | PCIe x8 HW-RAID Controller incl. ZMCP module (2 slots occupied) |
| Additional Storage | + 240 GB SSD (eMLC) SATA, in removable frame (front) |
| RAM | 32 GB DDR3 SDRAM (4 x 8 GB), ECC, dual channel |
| Industrial Ethernet | CP1623 |
| Pre-installed Software | PCS 7 V8.1 SP1 |
| Operating System (Pre-installed) | Windows Server 2008 R2 Standard edition incl. 5 clients, 64-bit, MUI (en/de/fr/it/es/cn) |
| Bus Module | 11 slots: 3x PCI, 3x PCIe x4, 5x PCIe x16 |
| Optical Drive | DVD +/-RW (slim) |
| Graphics (Multi-Monitor) | + Multi monitor with 4 screens PCIe x16 graphics card |
| Power Supply | 2 x 100/240V redundant power supply unit (without power supply cable) |
| Net Weight | 15,000 kg |
| Package Size Unit of Measure | Not available |
| Country of Origin | Germany |
