| MLFB Article No. |
6SL3710-1BD41-0AA0 |
| Product Series |
SINAMICS G150 Cabinet Drive Unit |
| Product Type |
AC/AC converter cabinet, 6-pulse diode infeed, no energy recovery (2-quadrant) |
| Rated Input Voltage |
3-phase 380–480 VAC, tolerance ±10%, short-time -15% within 1 min |
| Input Frequency Range |
47 Hz to 63 Hz |
| Rated Power Rating (Light Overload LO) |
500 kW / 670 HP |
| Rated Power Rating (Heavy Overload HO) |
400 kW / 535 HP |
| Rated Output Current (LO Mode) |
905 A |
| Rated Output Current (HO Mode) |
720 A |
| Max Output Frequency |
0–300 Hz |
| Factory Default Pulse Frequency |
1.25 kHz |
| Overload Capacity |
110% rated LO current for 60 s; 150% rated HO current for 60 s |
| Built-in Filter |
Standard integrated EMC filter, 2nd environment, Category C3 |
| Cabinet Version |
Version A compact cabinet design |
| Protection Class (Standard) |
IP20; optional IP21/IP23/IP43/IP54 |
| Control Unit |
CU320-2 control unit integrated, supports STARTER & TIA Portal |
| Control Modes |
V/f control, closed-loop vector control with encoder feedback |
| Cooling Method |
Forced air fan cooling |
| Cabinet Dimensions (H × W × D) |
2400 mm × 600 mm × 600 mm |
| Approximate Net Weight |
665 kg |
| Power Loss at Full LO Load |
9.7 kW |
| Sound Pressure Level (1 m distance) |
70 dB(A) |
| Max Terminal Cable Cross-section (IEC) |
4 × 240 mm² copper cable |
| Operating Ambient Temperature |
0 °C to +40 °C full load; derate power 1%/°C above 40 °C up to +50 °C |
| Storage & Transport Temperature |
-20 °C to +60 °C |
| Humidity Requirement |
5–85% RH, non-condensing, no corrosive gas |
| Max Operating Altitude |
≤1000 m without power derating; derate above 1000 m |
| Compliance Certifications |
CE, UL, CSA, RoHS industrial compliance |
| Country of Manufacture |
Germany |
| Product Lifecycle Status |
PM300 Active production |
| Typical Application |
Fans, pumps, compressors, conveyor constant-torque industrial equipment |
