6AV6647-0AG11-3AX0 (SIMATIC HMI TP1500 Basic Color PN) English Technical Specifications
The 6AV6647-0AG11-3AX0 is a SIMATIC HMI TP1500 Basic Color PN 15″ touch panel, with 24 V DC (19.2-28.8 V) power, 0.8 A rated input current, 20 W typical power, 32-bit RISC CPU, 1 MB RAM, 2 MB user data memory, PROFINET interface, and 15″ 1024×768 TFT display with 256 colors. Below is the detailed English specification table covering electrical and key technical parameters:
| Parameter | Value |
|---|---|
| Order Number | 6AV6647-0AG11-3AX0 |
| Product Type | SIMATIC HMI TP1500 Basic Color PN, 15″ Touch Panel, PROFINET Interface |
| Power Supply | 24 V DC (permissible range: 19.2–28.8 V DC, -20% / +20%) |
| Rated Input Current | 0.8 A (24 V DC, typical) |
| Inrush Current | I²t = 0.2 A²·s (starting inrush) |
| Active Power Consumption | Typical: 20 W |
| Display | 15″ TFT LCD; Resolution 1024×768 pixels; 256 colors; Resistive touch; LED backlight, MTBF 50,000 h (25 °C) |
| Processor | 32-bit RISC |
| Memory | RAM: 1 MB; User data memory: 2 MB |
| Communication Interfaces | 1× PROFINET (RJ45, 10/100 Mbps) |
| Protection Rating | Front: IP65; Housing: IP20 |
| Operating Temperature | 0-50 °C (non-condensing) |
| Storage Temperature | -20-60 °C |
| Dimensions (W×H×D) | 400 mm×310 mm×60 mm (front width×height×installation depth) |
| Weight | Approx. 4.5 kg |
| Certifications | CE, UL, RoHS compliant |
| Configuration Software | WinCC flexible 2008 SP2 Compact, WinCC Basic V10.5, STEP 7 Basic V10.5 |
| Lifecycle Status | Discontinued (Basic Panel 1st generation); Successor: 6AV2124-0GC01-0AX0 (TP1500 Comfort) |
