| Parameter Item | Specification |
|---|---|
| Part Number | 6AV7250-3KD00-0PA0 |
| Product Status | *** no longer available *** |
| Series Model | SIMATIC IPC 477D pro |
| Protection Rating | Fully protected IP65 |
| Display | 22″ multi-touch, 1920 × 1080 resolution |
| Mounting Design | Top flange, suitable for support arm & expansion assemblies |
| CPU | Core I3-3217UE (2C/4T, 1.6 GHz, 3 MB cache) |
| Memory | 8 GB DDR3 SDRAM |
| Harddisk | 240 GB SATA SSD, replaceable without drive |
| Power Supply | 24 V DC industrial power supply |
| Network Interfaces | 2 × Gbit Ethernet (IE/PN), 10/100/1000 Mbps |
| USB Ports | 4 rear USB ports, no front USB interface |
| Serial Port | 1 × RS-232 COM port |
| Operating System | Windows 7 Ultimate SP1, 32-bit, MUI (en/de/fr/it) |
| SIMATIC Software | Not pre-installed |
