6SL3310‑1GF34‑1AA3
Overview of 6SL3310-1GF34-1AA3
The 6SL3310-1GF34-1AA3 is a high-performance power module from the Siemens SINAMICS G130 series, designed for heavy-duty industrial single-drive applications. It adopts a 6-pulse non-regenerative rectifier topology, suitable for 3AC 500–600 V power supply systems with rated continuous current of 410 A and typical rated power up to 250 kW. With IP00 protection degree, it is intended for internal cabinet installation and equipped with forced air cooling to ensure stable long-term operation.
Supporting 50/60 Hz grid frequency, the module features standard Drive-CLiQ communication interface for seamless connection with CU control units and other system components. It operates reliably within 0 °C to +40 °C without power derating and meets CE, UL and cUL certification standards. Widely applied in fans, pumps, compressors and general heavy machinery, it delivers high efficiency, strong overload capability and outstanding operational stability for industrial variable speed drive systems.
| Parameter Item | Specification |
|---|---|
| Model No. | 6SL3310-1GF34-1AA3 |
| Product Series | SINAMICS G130 |
| Module Type | Power Module, 6-pulse rectifier, non-regenerative |
| Rated Input Voltage | 3AC 500–600 V (±10%) |
| Rated Frequency | 50 / 60 Hz |
| Rated Input Current | 410 A continuous |
| Typical Rated Power | 250 kW |
| Protection Class | IP00 (cabinet internal mounting) |
| Cooling Method | Internal forced air cooling |
| Operating Temperature | 0 … +40 °C (no derating) |
| Storage Temperature | -25 … +55 °C |
| Scope of Supply | Integrated CIM interface module, Drive-CLiQ interface; without CU control unit |
| Communication Interface | Drive-CLiQ |
| Approx. Weight | 294 kg |
| Certification | CE, UL, cUL |
