| Parameter | Specification |
|---|---|
| Part Number | 7ME6910-1AA10-1AA0 |
| Product Series | SITRANS FM / MAG 5000 |
| Product Type | Electromagnetic Flow Transmitter |
| Compatible Sensor | MAG 1100 / MAG 3100 P / MAG 5100 W |
| Power Supply | 115–230 V AC, 50/60 Hz |
| Housing Material | Polyamide |
| Protection Class | IP67 / NEMA 4X/6 |
| Display | Backlit LCD display |
| Operation | 3-key local operation, multi-language menu |
| Measured Medium | Conductive liquid (≥5 μS/cm) |
| Input Impedance | ＞1×10¹⁴ Ω |
| Analog Output | 4–20 mA, programmable |
| Pulse / Frequency Output | Programmable, isolated |
| Relay Output | 1 programmable relay (alarm / control) |
| Communication | HART protocol |
| Operating Temperature | -20 °C … +60 °C |
| Storage Temperature | -40 °C … +70 °C |
| Weight | Approx. 0.83 kg |
| Mounting Type | Wall-mounted |
| Lifecycle Status | Obsolete, replacement: SITRANS FMT020 |
