20F1AGC104JA0NNNNN
PowerFlex Air Cooled 753 AC Drive
| Technical specifications for 20F1AGC104JA0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGC104JA0NNNNN |
| Weight | 32.00 lbs (14.51 kg) |
| Input Type | AC Input with Precharge, no DC Terminals |
| Enclosure | IP54, NEMA/UL Type 12 |
| Voltage Rating | 400V AC / 540V DC |
| Current Rating | 104 Amps |
| Power Rating | 55 kW |
| Filtering | Yes |
| Default CM Cap Connection | Jumper installed |
| Internal Resistor | No |
| Internal Transistor | Yes |
| Door Mounted HIM | No Door Mounted HIM |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -40 to 70 °C |
| Relative Humidity | 5 to 95% |
| Certifications | CE, ABS, EAC, KCC |
