6AV7261-0CE13-2AA0
SIMATIC IPC677E(Panel PC), 19″ Multitouch (1920×1080); UHD graphic onboard; DP/DVI-D; 3x Gigabit Ethernet (IE/PN); 6x USB 3.1 Gen. 2; 1x serial (COM 1); RAID controller onboard; Watchdog, temperature and fan monitoring; Core i3-8100 (4C/4T, 3.6 GHz, 6 MB cache, VT-d); RAID1 2x SSD SATA 2.5″ 480 GB Internal; 8 GB DDR4-2666(2×4); 110/230 V AC industrial power supply unit With NAMUR; Power supply cable USA; Windows 10 Enterprise 2019 LTSC, 64-bit, MUI (en, de, fr, it, es) For Celeron and Core I3; Without extension (software); Without extension (HW); 2x PCI
| Order Number | 6AV7261-0CE13-2AA0 |
| Product Family | SIMATIC IPC677E (Panel PC) |
| Product Type | Industrial Panel PC |
| Display | 19″ Multitouch (1920 × 1080) |
| Graphics | UHD graphics onboard; DP / DVI‑D outputs |
| Ethernet Interfaces | 3 × Gigabit Ethernet (IE/PN – Industrial Ethernet / PROFINET) |
| USB Interfaces | 6 × USB 3.1 Gen. 2 |
| Serial Interface | 1 × serial (COM 1) |
| Storage Controller | RAID controller onboard |
| System Monitoring | Watchdog timer, temperature and fan monitoring |
| Processor | Intel Core i3‑8100 (4 cores / 4 threads, 3.6 GHz, 6 MB cache, VT‑d) |
| Storage Configuration | RAID1: 2 × SSD SATA 2.5″ 480 GB (internal) |
| System Memory (RAM) | 8 GB DDR4‑2666 (2 × 4 GB) |
| Power Supply | 110/230 V AC industrial power supply unit with NAMUR compliance (includes USA power cable) |
| Operating System | Windows 10 Enterprise 2019 LTSC, 64‑bit, MUI (Multilingual User Interface) – supported languages: English, German, French, Italian, Spanish; for Celeron and Core i3 |
| Pre‑installed Software | Without additional software expansions (base configuration only) |
| Hardware Expansions | Without additional hardware expansions (base configuration only) |
| Expansion Slots | 2 × PCI slots |
| Net Weight | 17.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | Germany |
