6AV7892-1AB00-1AB0
***No longer available*** SIMATIC HMI IPC677C (Panel PC), 2×10/100/1000 Mbit/s Ethernet; 4 x USB V2.0, 1x serial (COM1); Watchdog, temperature and fan monitoring; RAID controller onboard; 15″ Touch; 1024x 768 without front-side USB-Schnittstelle 24 V DC power supply Celeron P4505 (2C/2T, 1.86 GHz, 2 MB cache); PROFIBUS/MPI (CP 5611-A2-compatible); 2 MB buffered SRAM 1 GB DDR3 1066 DIMM; 250 GB HDD SATA DVD+-R+-RW; 2x PCI free Windows XP Prof. SP3 MUI (de, en, fr, es, it) without expansion (software)
| Order Number | 6AV7892-1AB00-1AB0 |
| Product Family | SIMATIC HMI IPC677C (Panel PC) |
| Product Type | Industrial Panel PC |
| Ethernet Interfaces | 2 × 10/100/1000 Mbit/s Ethernet |
| USB Interfaces | 4 × USB V2.0 (without front‑side USB interface) |
| Serial Interface | 1 × serial (COM1) |
| System Monitoring | Watchdog timer, temperature and fan monitoring |
| Storage Controller | RAID controller onboard |
| Display | 15″ Touch, 1024 × 768 |
| Power Supply | 24 V DC power supply |
| Processor | Intel Celeron P4505 (2 cores / 2 threads, 1.86 GHz, 2 MB cache) |
| Fieldbus Interface | PROFIBUS / MPI (CP 5611‑A2‑compatible) |
| Retentive Memory | 2 MB buffered SRAM |
| System Memory (RAM) | 1 GB DDR3 1066 DIMM |
| Mass Storage | 250 GB SATA HDD |
| Optical Drive | DVD ± R ± RW |
| Expansion Slots | 2 × PCI slots (free / available) |
| Operating System | Windows XP Professional SP3 MUI (Multilingual User Interface) – supported languages: German, English, French, Spanish, Italian |
| Pre‑installed Software | No additional expansion software included (base configuration only) |
| Net Weight | 17.450 kg |
| Packaging Dimensions | Not available |
| Country of Origin | Germany |
